- Page 1 XR1000 Framing PR-2727 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com 1/22...
-
Page 2: Table Of Contents
INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR FITTING THE LAMP POWER SUPPLY – MAINS CONTROL CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS OPERATION MENU ERROR MESSAGES REPLACING GOBOS DMX PROTOCOL LED INDICATION MAINTENANCE LUBRICATION KEEPING THE PROJECTOR CLEAN TROUBLESHOOTING... - Page 3 FE USAGE E OF THE E PROJEC CTOR When unpac cking and befor re disposing of the carton chec ck there is no tr ransportation da amage before u using the project tor. Should ther be any dama age caused by tr ransportation, co onsult your dea aler and do not u...
-
Page 4: Fitting The Lamp
To pass the SAFETY CORD through the HOLES for safety! Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning. Always ensure that the structure that you are going to mount the projector to is secure and strong enough to support the weight of a XR 1000 Framing WARNING: 1. -
Page 5: Power Supply – Mains
Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. XLR plugs and sockets mustn’t be connected in any way other than mentioned in the above figure. The XR 1000 Framing accepts digital control signals in protocol DMX512 (1990). -
Page 6: Dmx Terminator
X R 1 0 0 0 F ra m in g Each XR 1000 Framing must be given a DMX start address so that the correct projector responds to the correct control signals. This DMX start address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the controller. -
Page 7: Operation Menu
OPERATION MENU First Menu Secondary Menu Third Menu Fourth Menu DMX Address DMX Address=XXX Reset Are You Sure Standard 16 DMX Mode Extended 16 （Default：Standard） Short 8 By Control Channel Lamp Control By Power On （Default：CHAN） By DMX Present Config Settings When DMX is Lost Normal time out Loss of DMX... - Page 8 Zoom Invert Zoom Invert Zoom Invert CYM Invert CYM Invert CYM Invert CTO Invert CTO Invert CTO Invert Defaults Defaults Defaults Restore Defaults Display On Always Display Mode Display Off After Delay Display Invert Display Invert Display Invert Disp Dim Level Disp Dim Level Disp Dim Level Disp Dim Level...
- Page 9 Pan and Tilt= Pan and Tilt XX℃ Head Sensor= Head Sensor XX℃ Display Board= Display Board X.X.X Driver Board 1= Driver Board 1 X.X.X Driver Board 2= Driver Board 2 X.X.X Driver Board 3= Software Version Driver Board 3 X.X.X Driver Board 4= Driver Board 4 X.X.X...
-
Page 10: Error Messages
Operation Mode= DMX Operation Operation Mode= Operation Mode Master Mode Operation Mode= Slave Mode Operation Mode= Static Scene User Memory 1 Scene Edit User Memory 1(1~200) User Memory 2 Static Scene User Memories Reset User 1 Reset User Memory 1 Unlock 2 3 44 Reset User 1 Init User Memory... -
Page 11: Replacing Gobos
Tilt Encoder Err Tilt Encoder Err Pan Enc T Out Pan Enc T Out Tilt Enc T Out Tilt Enc T Out Pan Sensor Error Pan Sensor Error Tilt Sensor Error Tilt Sensor Error Pan Over Temp Pan Over Temp Pan Driver Fault Pan Driver Fault Tilt Over Temp... -
Page 12: Dmx Protocol
DMX PROTOCOL Short Standard Extended FUNCTION DESCRIPTION mode mode Mode 000-010 Close 011-025 Open Strobe speed from slow to fast 026-225 Strobe Macro 1 226-239 Macro 2 240-241 242-246 Macro 3 247-255 Open 000-003 Close Dimming 004-255 Linear dimming （0-100%） Dimming Fine 0-255 Dimmer in 16 bit... - Page 13 114-120 Color7+ White 121-127 White 128-191 Rotation ,Clockwise from slow to fast Rotation, Anti-clockwise from slow to fast 192-255 Iris From Big to Small In size 000-255 Iris Fine 000-255 Iris in 16 Bit 000-010 White 011-072 Iris Effect 1 073-136 Iris Effect 2 137-198...
- Page 14 206-215 Shake of Gobo 3 216-225 Shake of Gobo 4 226-235 Shake of Gobo 5 Shake of Gobo 6 236-245 Shake of Gobo 7 246-255 000-127 Gobo Indexing Stop Gobo Rotation 129-188 Rotation （Clockwise From slow to Fast） 189-195 Stop 196-255 Rotation （Anti-Clockwise From slow to Fast）...
-
Page 15: Led Indication
000-255 Zooming Fine Linear Zooming in 16 bit precision 000-255 Pan(0°~540°) Pan Fine 000-255 Pan in 16 bit precision Tilt 000-255 Tilt(0°~270°) Tilt Fine 000-255 Tilt in 16 bit precision Pan & Tilt Speeds 000-255 Pan & Tilt Speed from Fast to Slow 000-047 Reserved Reset... -
Page 16: Keeping The Projector Clean
KEEPING THE PROJECTOR CLEAN To ensure the reliability of the projector it should be kept clean. It is recommended that the fans should be cleaned every 15 days. The lens and dichroic colour filters should also be regularly cleaned to maintain an optimum light output. Do NOT use any type of solvent containing chemical elements on dichroic colour filters. -
Page 17: Technical Data
TECHNICAL DATA VOLTAGES: 200V~240V AC，50/60Hz POWER CONSUMPTION: 1200W@220V LAMP: OR: PHILIPS MSR GoldTM 1000 MiniFastFit OSRAM HTI 1000W/PS Colour Temperature 5800K Colour Temperature 6000k Socket PGJX36 Socket PGJX36 Manufacturers Rated Lamp Life 750hours Manufacturers Rated Lamp Life 900hours Colors: CMY linear mixing system with macros 1 color wheel: 7colors+ 1 White Half color effect, rainbow effect with bi-directional and variable speeds Stepping/linear color changing... - Page 18 DMX linear Zooming DIMMER: 0-100% linearly adjustable IRIS: 5-100% linearly adjustable Macro SHUTTER: Double shutter blades, 0.3~25 F.P.S Macro HEAD MOVEMENT: Pan 540º, Tilt 270º with auto position correction BEAM ANGLE: 11°-51°, Linear Adjustment in 16 bit CONTROL: DMX512, 3 pin and 5 pin interfaces 30channels in short mode, 36channels in standard mode and 51channels in extended mode Self-test mode OTHER FUNCTIONS:...
- Page 19 SIZES: LIGHT OUTPUT: 51°（lux） 1047 30118 7530 3346 1882 1205 11°（lux） 11° 51° DISTANCE （m） 0m 11° DIAMETER （m） 0.98 1.96 2.95 3.93 4.91 5.89 51° DIAMETER （m） 0 4.49 8.98 13.47 17.96 22.45 26.94 19/22...
- Page 20 M2-5 M3-1 M3-2 /STROBE 1 1/Focus1 1/Zoom1 A C B D A C B D A C B D M1-1 M1-2 M1-3 M1-4 M1-5 M1-6 M2-1 M2-2 M2-5 M2-6 M3-1 M3-2 M3-3 M3-4 M3-5 M3-6 M4-1 M4-2 M4-3 M4-4 M4-5 M4-6 /Colour /CTO...
- Page 21 omponent Order Code NAME PART NO. QUANTITY REMARK PAN MOTOR 030040178 030040178 TILT MOTOR 030040186 DIMMER MOTOR 030040210 STROBE MOTOR 030040211 CYM MOTOR 030040212 ROTATING GOBO WHEEL MOTOR FIXED GOBO WHEEL MOTOR 030040215 COLOR WHEEL MOTOR 030040217 IRIS MOTOR 030040221 030040218 ROTATOR MOTOR 030040219...
- Page 22 PR LIGHTING LTD. 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320020234 Version: 20150109 22/22...
