PRODUCT SPECIFICATIONS

CINTIQ 12WX (MODEL DTZ-1200W) GENERAL SPECIFICATIONS

Dimensions (W x D x H)
Weight
Input voltage
Power consumption
Operating temperature and humidity
Storage temperature and humidity
Certification and compliance

DISPLAY

Display
Screen size
Aspect ratio
Supported resolutions
Synchronization range
Pixel pitch
Color depth
Pixels
Response time (refresh rate)
Brightness
Contrast ratio
Plug and Play
LCD quality
405 x 270 x 17 mm (15.96 x 10.64 x 0.67 in), excluding rotation pivot
2.0 kg (4.4 lb)
12 VDC
29 W or less in normal operation mode
2 W or less in suspend or standby modes
1 W or less in off mode
5° to 35° C, 20 to 80% RH (non-condensing)
-10° to 60° C, 20 to 90% RH (non-condensing)
(maximum storage humidity is 38% at a temperature of 60° C, and
maximum storage temperature is 42° C at a humidity of 90%)
FCC Part 15 Class B & Subpart C, CE, VCCI Class B, EDID 1.3, C-tick,
MIC, BSMI, CCC, RoHS, GOST-R, Industry Canada, Class B
a-Si TFT active matrix LCD
310 mm (12.1 in) diagonal, 261.1 x 163.2 mm (10.3 x 6.4 in)
16 : 10, approximately
1280 x 800 pixels (WXGA) maximum, 1024 x 768 pixels (XGA),
800 x 600 pixels (SVGA), 640 x 480 pixels (VGA), and others
60 Hz vertical (for WXGA)
56 to 75 Hz vertical, 31 to 82 kHz horizontal
(for resolutions less than WXGA)
0.204 x 0.204 mm (0.01 x 0.01 in)
16,777,216 colors (8 bits per color)
1,024,000
25 ms typical (rise and fall)
2
180 cd/m (maximum)
600:1
DDC-2B, DDC/CI, and other DVI standards
Each Cintiq LCD panel is produced under stringent quality standards.
Production techniques cannot guarantee an absolutely perfect TFT
display. Wacom does not allow any pixel to be always white or always
black. A small number of sub-pixels (7 or less) can be partially on or
partially off – this does not mean the display is defective.
