Installation Instructions
REV 5 11/17/21
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
Part No.
3930
Product: Running Boards
Application:
Level of Difficulty:
Installation Time: 60 Min
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Toyota Tundra
Double Cab 2007-2021
1
2 3 4 5
Advertisement
Related Manuals for Romik 3930
Summary of Contents for Romik 3930
- Page 1 Part No. 3930 Product: Running Boards Application: Toyota Tundra Double Cab 2007-2021 Installation Instructions Level of Difficulty: 2 3 4 5 Installation Time: 60 Min REV 5 11/17/21 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 2 Installation Instructions 3930 Bracket Kit Step 1: Locate bracket mounting locations and hardware as per 1 page of this installation manual and above image Step 2: Locate front bracket mounitng area, remove factory bolt and dispose Figure 1. Step 3: Using provided M8 hardware install front bracket Figure 2. Do not tighten...
- Page 3 Installation Instructions 3930 Bracket Kit Step 6: Locate rear bracket mounting area, remove factory bolts and dispose Figure 5 Step 7: Using provided M8 hardware install rear bracket Figure 6 Do not tighten Figure 5 Figure 6 Remove M8 Bolts...
- Page 4 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
