REV 3 04/15/20
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
Part No.
Product: Running Boards
Application:
Subaru XV/Crosstrek 2014+
Level of Difficulty: 1
Installation Time: 60 min
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
3612
2
3 4 5
Advertisement
Table of Contents
Related Manuals for Romik 3612
Summary of Contents for Romik 3612
- Page 1 Part No. 3612 Product: Running Boards Application: Installation Instructions Subaru XV/Crosstrek 2014+ Level of Difficulty: 1 3 4 5 Installation Time: 60 min REV 3 04/15/20 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 2 Video Installation Installation Instructions 3612 Bracket Kit Instruction: Note: Some models may require plastic undercarriage trimming Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Step 2: Remove factroy rubber plug, install provided HTC 243 as show Figure 1...
- Page 3 Step 6: Proceed to last page of this manual for running board install instructions and torque values For Technical support please call our team at 1-866-717-6645 and one of our experts will assist you with this installation. Thank you for choosing Romik.
- Page 4 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
