Installation Instructions
REV 1 02/11/20
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Part No.
1619-2D/3D
Product:
Romik Connect
Running Boards
Application
:
Dodge RAM ProMaster 2014+
Level of Difficulty: 1 2 3
Installation Time: 90 Min
4
5
Advertisement
Table of Contents
Related Manuals for Romik 1619-2D
Summary of Contents for Romik 1619-2D
- Page 1 Part No. 1619-2D/3D Product: Romik Connect Running Boards Application Installation Instructions Dodge RAM ProMaster 2014+ Level of Difficulty: 1 2 3 Installation Time: 90 Min REV 1 02/11/20 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 2 Video Installation Installation Instructions 1619-2D / 3D Bracket Kit Instruction: Step 1: Separate brackets and hardware as per 1 page of this installation manual. Please note bracket positioning for Long Wheel Base 5,8,2,1 and Short Wheel Base models 5,8,1,2. Step 2: Driver’s side front, remove factory rubber plugs as shown on Figure 1 TIP: Try to preassemble the bracket for easier placement.
- Page 3 Installation Instructions 1619-2D / 3D Bracket Kit Step 6: Pass Front, remove factory rubber plugs as shown on Figure 5 pre-assemble the bracket for easier placement. Install provided HTC 243 Figure 5 HTC 243 Step 7: Bring pre-assembled bracket and install onto HTC 243 and secure, push clamp end onto the vehicle chassis lip push up and secure Figure 6.
- Page 4 Installation Instructions 1619-2D / 3D Bracket Kit Pre-assemble Pass 3 bracket Figure 13, install HTC 243 on shown locations Figure 14. Attach pre- Step 8: assembled bracket as shown on Figure 15. Do not tighten Please note bracket positioning for Long Wheel Base 5,8,2,1 and Short Wheel Base models 5,8,1,2.
- Page 5 Step 2: Remove plastic endcap as shown on Figure A1 – A4 keep screws as they will be re-used. Step 3: Remove Romik Connect plate and assemble as show on Figure B1 – B3 using original screws. Join two running boards together using supplied M8 bolts torque to 7 ft lbs.
- Page 6 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
