Installation Instructions

REV 2 12/01/22

Hardware

Torque Aluminum Torque Steel to Steel

M6 Bolt

3 ft-lbs.

M8 Bolt

7 ft-lbs.

M10 Bolt

16 ft-lbs.

M12 Bolt

28 ft-lbs.

ATTENTION: Use correct torque settings to avoid

14 ft-lbs.

damaging the running boards and or mounting

35 ft-lbs.

brackets. Failure to do so will void your warranty. If

64 ft-lbs.

you have any questions, please contact our technical

112 ft-lbs.

team at 1-866-717-6645

Part No.

3412

Product: Running Boards

Application:

Porsche Macan 2017 - 2021

Level of Difficulty: 1 2

Installation Time: 120 Min.

4 5

Need help?

Do you have a question about the 3412 and is the answer not in the manual?

Page 1 Part No. 3412 Product: Running Boards Application: Porsche Macan 2017 - 2021 Installation Instructions Level of Difficulty: 1 2 Installation Time: 120 Min. REV 2 12/01/22 ATTENTION: Use correct torque settings to avoid Hardware Torque Aluminum Torque Steel to Steel M6 Bolt 3 ft-lbs.
Page 3 Important Install Tip: When installing Romik HTC inserts follow the sequence below. Make sure the HTC is seated correctly and do not use power tools as this will only spin the insert and possibly damage it. Test by tugging on it before installing braket.
Page 4 Installation Instructions 3412 Bracket Kit Step 4: Locate rear bracket mounting area Figure 4. Install provided HTC 230 #5 and install rear main bracket #3. Do not tighten. Figure 4 Step 5: Install HTC 232 as shown on Figure 5. Attach rear extra support bracket #4, using supplied hardware #8, #9 attach the two brackets together Figure 6.
Page 5 2X per year. Wash often with mild soap and make sure to remove all soap residue. Many car automatic carwashes use a strong soap, make sure to use enough water to remove all residue. For video instructions on how to clean your Romik products please click here https://romik.com/cleaning...
