Installation Instructions
REV 3 04/15/20
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
Part No.
Product: Running Boards
Application:
Subaru Outback 2015-2019
Level of Difficulty: 1
Installation Time: 60 min.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
3615
2
3 4 5
Advertisement
Table of Contents
Related Manuals for Romik 3615
Summary of Contents for Romik 3615
- Page 1 Part No. 3615 Product: Running Boards Application: Installation Instructions Subaru Outback 2015-2019 Level of Difficulty: 1 3 4 5 Installation Time: 60 min. REV 3 04/15/20 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 2 Video Installation Installation Instructions 3615 Bracket kit Instruction: Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Step 2: Remove factory rubber plug and 10mm bolt Figure 1. Discard as they will not be needed.
- Page 3 Installation Instructions 3615 Bracket kit Step 3: Remove factory rubber plug, install provided HTC 262 as shown Figure 4. Figure 4 Step 4: Install rear bracket, start by pointing the brackets towards the front of the vehicle, attach 10mm and proceed to turn bracket outwards.
- Page 4 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
