Installation Instructions
REV 3 04/15/20
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Part No.
3230
Product: Running Boards
Application:
Nissan Murano 2015+
Level of Difficulty: 1
2
Installation Time: 60 min.
3 4 5
Advertisement
Related Manuals for Romik 3230
Summary of Contents for Romik 3230
- Page 1 Part No. 3230 Product: Running Boards Application: Installation Instructions Nissan Murano 2015+ Level of Difficulty: 1 3 4 5 Installation Time: 60 min. REV 3 04/15/20 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 2 Video Installation Installation Instructions 3230 Bracket Kit Instruction: NOTE: Will not fit models with factory “puddle” lights Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Step 2: Install provided HTC 230 as shown Figure 1.
- Page 3 Installation Instructions 3230 Bracket Kit Step 5: Locate middle bracket support are and remove rubber plugs Figure 6. Install middle bracket as shown Figure 7. Do not tighten Figure 6 Figure 7 Step 6: Locate rear bracket mounting area, Take the special insert and install as shown figure 8.
- Page 4 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
