Installation Instructions
REV 4 09/15/24
Hardware
Torque Aluminum Torque Steel to Steel
M6 Bolt
3 ft-lbs.
M8 Bolt
7 ft-lbs.
M10 Bolt
16 ft-lbs.
M12 Bolt
28 ft-lbs.
Attention: Please make sure that you have the latest instructions
from Romik.com
ATTENTION: Use correct torque settings to avoid
14 ft-lbs.
damaging the running boards and or mounting
35 ft-lbs.
brackets. Failure to do so will void your warranty. If
64 ft-lbs.
you have any questions, please contact our technical
112 ft-lbs.
team at 1-866-717-6645
Part No.
1434
Product: Running Boards
Buick Enclave 2018 – 2024
Application:
Chevrolet Traverse 2018 – 2023
Level of Difficulty: 1 2
Installation Time: 90 Min.
QR Scan
3
4 5
Advertisement
Related Manuals for Romik 1434
Summary of Contents for Romik 1434
- Page 1 Part No. 1434 Product: Running Boards Buick Enclave 2018 – 2024 Application: Installation Instructions Chevrolet Traverse 2018 – 2023 Level of Difficulty: 1 2 Installation Time: 90 Min. REV 4 09/15/24 ATTENTION: Use correct torque settings to avoid Hardware Torque Aluminum Torque Steel to Steel M6 Bolt 3 ft-lbs.
- Page 3 Important Install Tip: When installing Romik HTC inserts follow the sequence below. Make sure the HTC is seated correctly and do not use power tools as this will only spin the insert and possibly damage it. Test by tugging on it before installing braket.
- Page 4 Installation Instructions 1434 Bracket Kit Image shows pass front bracket installed Step 4: Locate middle bracket position, Install provided HTC 311 as shown Figure 5, Remove factory rubber plug as shown Figure 6. Install provided HTC 243 Figure 7. Step 5: Install middle bracket Figure 8. Do not tighten...
- Page 5 Installation Instructions 1434 Bracket Kit Step 6: Locate rear bracket position Figure 8, Install provided HTC 284. Remove factory rubber plug Figure 9 and install proviced HTC 243 Figure 10. Step 7: Install rear bracket as show Figure 11 and 12 Do not tighten...
- Page 6 2X per year. Wash often with mild soap and make sure to remove all soap residue. Many car automatic carwashes use a strong soap, make sure to use enough water to remove all residue. For video instructions on how to clean your Romik products please click here https://romik.com/cleaning...
