Installation Instructions

REV 3 04/15/20

Hardware

M6 Bolt

M8 Bolt

M10 Bolt

M12 Bolt

Torque Specifications

3 ft-lbs.

7 ft-lbs.

16 ft-lbs.

28 ft-lbs.

long

ATTENTION: Use correct torque settings to avoid

damaging the running boards and or mounting

brackets. Failure to do so will void your warranty.

If you have any questions please contact our technical

team at 1-866-717-6645

short

Part No.

3411

Product: Running Boards

Application:

Porsche Cayenne 2011-2017

Level of Difficulty: 1 2

Installation Time: 90 min

4 5

Need help?

Do you have a question about the 3411 and is the answer not in the manual?

Page 1 Part No. 3411 Product: Running Boards Application: Installation Instructions Porsche Cayenne 2011-2017 Level of Difficulty: 1 2 Installation Time: 90 min REV 3 04/15/20 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs. damaging the running boards and or mounting M8 Bolt 7 ft-lbs.
Page 2 Video Installation Installation Instructions 3411 Bracket Kit Instruction: Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Note: Long front bracket is passenger and short front bracket is driver’s. Depending on the model European or North American remove undercarriage panels and trim once brackets are installed.
Page 3 Installation Instructions 3411 Bracket Kit Step 5: Proceed to install extra support hardware HTC 230 as shown Figure 5. Attach extra support to main support using supplied M10 hardware. Do not tighten Figure 5 Step 6: Proceed to last page of this manual for running board install instructions and torque values Step 7: Re-install undercarriage panels, using a utility knife scribe and cut where brackets and panel makes contact.
Page 4 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
