Installation Instructions
REV 3 04/01/20
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Part No.
2619
Product: Running Boards
Application:
Jeep Cherokee 2014+
Level of Difficulty: 1 2 3
Installation Time: 90 min
4
5
Advertisement
Related Manuals for Romik RZR
Summary of Contents for Romik RZR
- Page 1 Part No. 2619 Product: Running Boards Application: Installation Instructions Jeep Cherokee 2014+ Level of Difficulty: 1 2 3 Installation Time: 90 min REV 3 04/01/20 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs. damaging the running boards and or mounting M8 Bolt 7 ft-lbs.
- Page 2 NOTE: This installation requires drilling. Cherokee Trailhawk owners can order Jeep Cherokee original side cladding 1YW36RXFAG and 1YW37RXFAG in order to install Romik running boards. Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Step 2: Remove factory 10mm nut Figure 1 DO NOT DISCARD.
- Page 3 Step 11: Proceed to last page of this manual for running board install instructions and torque values For Technical support please call our team at 1-866-717-6645 and one of our experts will assist you with this installation. Thank you for choosing Romik.
- Page 4 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
