Installation Instructions
REV 1 01/25/22
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
Part No.
Product: Running Boards
Application:
Level of Difficulty: 1 2 3
Installation Time: 120 Min
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
4050
VW Atlas 2018+
4
5
Advertisement
Related Manuals for Romik RZR
Summary of Contents for Romik RZR
- Page 1 Part No. 4050 Product: Running Boards Application: VW Atlas 2018+ Installation Instructions Level of Difficulty: 1 2 3 Installation Time: 120 Min REV 1 01/25/22 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs. damaging the running boards and or mounting M8 Bolt 7 ft-lbs.
-
Page 3: Professional Installation Recommended
Important Install Tip: When installing Romik HTC inserts follow the sequence below. Make sure the HTC is seated correctly and do not use power tools as this will only spin the insert and possibly damage it. Test by tugging on it before installing braket. - Page 4 Move to the rear panel and starting at the back make a marking at 8 inch / 20.32 cm and 9 inch / 22.86 cm cut a 3.75 inch 9.53 cm section. Proceed to install all plastic panels. For Technical support please call our team at 1-866-717-6645 and one of our experts will assist you with this installation. Thank you for choosing Romik.
- Page 5 NOTE: Use of power tools will damage the bottom of the running board and void your warranty. 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1.
