Installation Instructions
REV 7 12/02/21
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions, please contact our technical
team at 1-866-717-6645
Part No.
3027
Product: Running Boards
Application:
MB Sprinter 2007+
Level of Difficulty: 1 2 3 4
Installation Time:
120 + Min
5
Advertisement
Table of Contents
Related Manuals for Romik 3027
Summary of Contents for Romik 3027
- Page 1 Part No. 3027 Product: Running Boards Application: Installation Instructions MB Sprinter 2007+ Level of Difficulty: 1 2 3 4 Installation Time: 120 + Min REV 7 12/02/21 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 3 Installation Instructions 3027 Brackets “Professional Install recommended” Important Install Tip: When installing Romik HTC inserts. Test by tugging on it before installing braket. Blue loctite is highly recommended. Make sure the HTC is seated correctly and do not use power tools as this will only spin the insert and possibly damage it.
- Page 4 Installation Instructions 3027 Brackets “Professional Install recommended” Step 3: Proceed to install extra support and mark “pinch weld” for drilling. Push the extra support as high as possible making sure that the flat area touches the body of the vehicle. Drill two holes using a 15/64 drill bit.
- Page 5 Figure 5 Step 6: Once all the brackets are installed proceed and assemble the Romik “connect” running boards. Place the boards on the brackets and tighten them to our torque specs. NOTE: if necessary, use a level to make sure the running boards are properly installed.
- Page 6 Step 2: Remove plastic endcap as shown on Figure A1 – A4 keep screws as they will be re-used. Step 3: Remove Romik Connect plate and assemble as show on Figure B1 – B3 using original screws. Join two running boards together using supplied M8 bolts torque to 7 ft lbs.
- Page 7 NOTE: Use of power tools will damage the bottom of the running board and void your warranty. 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1.
