Installation Instructions
REV 1 02/26/20
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Part No.
2137 2D / 3D
Product:
Romik Connect
Running Boards
Application:
Ford Transit 2014+
Level of Difficulty: 1 2
Installation Time: 90 Min
3
4 5
Advertisement
Table of Contents
Related Manuals for Romik 2137 2D
Summary of Contents for Romik 2137 2D
- Page 1 Part No. 2137 2D / 3D Product: Romik Connect Running Boards Application: Installation Instructions Ford Transit 2014+ Level of Difficulty: 1 2 Installation Time: 90 Min REV 1 02/26/20 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 2 Video Installation Installation Instructions 2137-2D / 3D Bracket Kit Instruction: Step 1: Locate mounting locations and hardware as per 1 page of this installation manual Step 2: Pre-assemble front drivers bracket for easy installation. If equiped with mudflaps remove screw holding mudflap bracket as shown on Figure 1.
- Page 3 Installation Instructions 2137-2D / 3D Bracket Kit Step 5: Pre-assemble passenger side front bracket. Locate mounting points and install provided HTC 243 and M10 bolt If equiped with mudflaps please review step 2 . Figure 9 Figure 10 HTC 243 Step 6: Install pre-assembled bracket do not tighten Step 7: Pre-assemble bracket pass second bracket as shown on Figure 11, install provided HTC 243 as shown on Figure 12.
- Page 4 Step 11: Proceed to last page of this manual for running board install instructions and torque values For Technical support please call our team at 1-866-717-6645 and one of our experts will assist you with this installation. Thank you for choosing Romik.
- Page 5 Step 2: Remove plastic endcap as shown on Figure A1 – A4 keep screws as they will be re-used. Step 3: Remove Romik Connect plate and assemble as show on Figure B1 – B3 using original screws. Join two running boards together using supplied M8 bolts torque to 7 ft lbs.
- Page 6 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
