Installation Instructions
REV 1 02/10/20
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Part No.
2332
Product: Running Boards
Application:
Hyundai Palisades 2020+
Kia Telluride 2020+
Level of Difficulty: 1
2
Installation Time: 90 Min
3 4 5
Advertisement
Table of Contents
Related Manuals for Romik 2332
Summary of Contents for Romik 2332
- Page 1 Part No. 2332 Product: Running Boards Application: Hyundai Palisades 2020+ Installation Instructions Kia Telluride 2020+ Level of Difficulty: 1 3 4 5 Installation Time: 90 Min REV 1 02/10/20 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 2 Video Installation Installation Instructions 2332 Bracket Kit Instruction: NOTE: This vehicle requires undercarriage panel trimming Step 1: Remove lower undercarriage panels. Front Figure 1 Figure 1 Step 2: Locate front mounting locations and hardware as per 1 page of this installation manual...
- Page 3 Installation Instructions 2332 Bracket Kit Step 6: Remove factory rubber plug on rear inner mounting area Figure 5 install supplied HTC 262 Figure 5 HTC 262 Step 7: Remove factory rubber plug on rear outer mounting area Figure 6 install supplied HTC 230...
- Page 4 Installation Instructions 2332 Bracket Kit Step 9: Trim a 2 x 2 square in the middle bracket location as show Figure 9 Figure 9 Step 10: Install panels back onto vehicle. Step 11: Install front bracket as shown Figure 10 Do not tighten...
- Page 5 Installation Instructions 2332 Bracket Kit Step 13: Install rear bracket as shown Figure 12 Do not tighten Figure 12 Step 14: Proceed to last page of this manual for running board install instructions and torque values For Technical support please call our team at 1-866-717-6645 and one of our experts will assist you with this installation.
- Page 6 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
