activTek Air Scrubber+ Ozone Use And Operation page 4

Duct mounted air & surface purification system

Advertisement

PRODUCT FEATURES
It is important to be familiar with the parts of the Air Scrubber
contact your sales representative or Customer Service at 866.736.0503 or email support@activtek.net.
UV Bulb
Indicator
INSTALLATION HARDWARE (SUPPLIED)
(2) Black thumb nuts
(4) Off-white thumb nuts
RECOMMENDED INSTALLATION TOOLS
CAUTION
3 1/2" Hole Saw
(for wood or metal)
YOU MAY ALSO NEED:
Utility Knife
4
activTek Cell Assembly
(Includes UV Bulb)
Intermediate Mounting Plate
Power Cable
(8) #8 — .75
1/4" Self-tapping screws
When the unit is installed in a roof mounted HVAC system, the unit must
be protected from elements.
Drill / Power
Driver
Tin Snips
(for metal ductwork)
Ozone by activTek. If any parts are missing,
+
(4) #6 — 32 x 2" Threaded bolts
Phillips
Screwdriver
Dust Mask
Safety Switch
(4) #6 — 32 Toggle
bolt wall anchors
3/8" Drill Bit
(if installing into fiberglass
ducting with toggle bolts)
Duct
Mounting Plate
1/4
1/4" Nut
Driver Bit
