PORTABLE ELECTRONIC PURIFIER

READ MANUAL CAREFULLY FOR PROPER USE AND OPTIMAL OPERATION.

Need help?

Do you have a question about the Air Scrubber Mobile+ Ozone and is the answer not in the manual?

Questions and answers

Summary of Contents for activTek Air Scrubber Mobile+ Ozone

Page 1 PORTABLE ELECTRONIC PURIFIER READ MANUAL CAREFULLY FOR PROPER USE AND OPTIMAL OPERATION.
Page 2 FILL IN AND SAVE Warranty: • Limited 1 year warranty Record information regarding your new Air Scrubber Mobile Ozone by activTek here. Retain for future reference. We reserve the right to change or modify any specification without notice. Model No.
Page 3 IMPORTANT SAFETY INSTRUCTIONS • UV Lamp in operation • Do not operate the Air Scrubber Mobile Ozone by activTek unless the case is completely and ® correctly assembled; failure to comply may result in serious eye damage WARNING • Do not operate unit near heat sources, open flame, or combustible vapors or gases •...
Page 4 A. Wire Stand (9950153) B. Base (9950154) C. Knob/Clamp Pack (2) (9950155) D. 12 Volt DC Adapter (9950157) E. 2.0 AMP Fuse (9950162) AC Adapter (9950158) G. activTek Bulb Assembly Service Kit (9950209) ® A. WIRE STAND B. BASE C. KNOB/CLAMP PACK (2) D.
Page 5 2. Adjust the Wire Stand (see page 6). 3. Plug in either the 12 Volt DC Car Adapter or the AC Adapter. 4. The Air Scrubber Mobile Ozone by activTek unit will come on when power is supplied to the unit. ®...
Page 6 The Wire Stand on the Air Scrubber Mobile Ozone by activTek allows for quick release from the Base, provides a stand or hanger for the unit independent of the Base, and allows the unit to either stand or hang from the Base depending on how the Base is mounted.
Page 7 Air Scrubber Mobile Ozone by activTek with the 12 Volt DC adapter. POWER ADAPTERS Not for use on 12 Volt positive ground or 24 Volt vehicles. Doing so may damage the product.
Page 8 PORTABILITY Depending on how it is mounted, your Air Scrubber Mobile Ozone by activTek can be ready to take with you in just a few seconds. ® SLIDE THEN LIFT PRESS •...
Page 9 CAUTION For maintenance and replacement of service kit 9950209 All user maintainable parts of the activTek Bulb Assembly Service Kit are accessed by removing the lower half of the case.
Page 10 3. Lift the small circuit board holding the target 4. Disconnect the leads of the activTek Bulb screen and bulb (activTek Bulb Assembly) Assembly from the main circuit board. from the two tabs. 5. Remove the activTek Bulb Assembly from the unit.
Page 11 9950153 to the main unit circuit board. B. BASE 9950154 C. KNOB/CLAMP PACK (2) 9950155 3. Carefully align the two holes in the activTek Bulb Assembly CIRCUIT D. 12VDC ADAPTER 9950157 to the two tabs on the main unit. BOARD E.
Page 12 • Remove the activTek Bulb Assembly, clean, and reinstall (see diagram on Page 10). • If cleaning and reinstalling does not correct the problem, replace the activTek Bulb Assembly (Service Kit # 9950209). • When looking through the rear inlet vents in low light you should see a slight bluish glow. If there is no glow, replace the activTek Bulb Assembly (Service Kit # 9950209).
Page 13 TARGET FRAME E. 2.0 AMP FUSE 9950162 Base ACTIVEPURE ® TARGET F. AC ADAPTER 9950158 UV BULB 12 Volt DC Adapter Wire Stand activTek® Bulb Assembly Service Kit To order replacement parts, contact Customer Service at 866.736.0503 or email support@activTek.net.
Page 14 For the latest information, please contact Customer If a valid serial number is missing from the product, the Service at 866.736.0503 or email support@activTek.net. warranty will be voided. activTek products are for sale through authorized Independent HVAC Contractors only. Warranties...
Page 15 Model: A1018C harmful interference in a residential installation. This equipment generates, uses, and can radiate radio Produced by: activTek Environmental, LLC frequency energy, and if not installed and used in accordance with the instructions, may cause harmful This device complies with Part 15 of the FCC Rules.
Page 16 For information regarding the use of this product please call Customer Service. 866.736.0503 support@activTek.net activTek Environmental, LLC 1300 Valley Drive Bristol, VA 24201 866.736.0503 © 2024 activTek Environmental, LLC. All Rights Reserved...
