activTek Air Scrubber+ Ozone Use And Operation page 10

REPLACING THE BALLAST (CONTINUED)
Power Cable
1. Disconnect (unplug)
Power Cable from unit.
4. Remove the two (2) nuts
securing ballast to the case.
Remove the ballast.
7. Replace cover and secure with
the original four (4) screws.
NOTE: Always follow OSHA electrical lockout safety requirements to prevent accidental release of energy
during service or maintenance activities.
For questions on maintenance procedures, contact
Customer Service at 866.736.0503 or email support@activTek.net
10
2. Open the ballast housing by
removing the four (4) screws,
then remove the cover.
5. Place new ballast into the original
location and secure using the two
(2) nuts removed in step 4.
UV Bulb
Indicator
8. Re-install unit if removed from
duct. Reconnect Power Cable, turn
breaker or fuse power back on and
check for proper operation.
NOTE: UV Bulb Indicator should be lit when in operation.
3. Disconnect all ballast
wiring by pressing down on
connector tabs and pulling
wire straight out.
6. To reconnect wiring, insert wire
into wire pocket in ballast until
bottomed. Gently pull wire to
ensure it is properly connected.
