activTek Air Scrubber+ Ozone Use And Operation page 6

INSTALLING THE UNIT
WARNING
CAUTION
Find the optimal position downstream from the air handler. Ensure location in duct has enough room for the
mounting plate. It is recommended for maximum effectiveness that the unit be placed as close to the air
handler as possible.
1. Locate suitable
area of duct for
installation.
ALTERNATE CUTTING METHOD:
a. Using the Duct Mounting
Plate, mark four cutting
method holes on duct.
6
To Reduce the Risk of Electric Shock – DO NOT use in wet or damp
locations. This equipment emits UV-C radiation. DO NOT locate
equipment in any location allowing direct line-of-sight to vents, returns,
or other duct openings. Disconnect from supply before servicing or
replacing.
• Hard wiring unit into HVAC system must be done by a licensed HVAC
installer or electrical contractor only
• When the unit is installed in a roof mounted HVAC system, the unit
must be protected from elements
• The Air Scrubber
install where power to the unit will be cycled on and off
2. Cut away insulation to
expose metal duct
(if needed).
b. Drill four holes where
marked.
Ozone by activTek
+ ®
3. Mark location for
3.5" opening using the
Duct Mounting Plate.
requires power 24/7; DO NOT
4. Cut hole in
Duct Mounting
Plate using
3.5" hole saw.
c. Cut between holes
using tin snips.
