- Page 1 ™ OWNER’S MANUAL • Installation • Operation • Specifications • Warranty ELECTRONIC AIR PURIFICATION SYSTEM 5420 LBJ Freeway, Suite 1010 Dallas, TX 75240 1.866.736.0503 CAUTION: Read manual carefully for proper procedures and operation.
- Page 2 -DO NOT ATTEMPT TO OPERATE THE FoodGUARD SYSTEM WITHOUT FIRST READING AND UNDERSTANDING ALL INFORMATION AS PROVIDED BY THE MANUFACTURER HEREIN. -DO NOT disassemble the FoodGUARD unit to service, or look directly inside at the ultraviolet light while it is operating.
-
Page 3: Table Of Contents
Warranty ................12 INTRODUCTION: Thank you and congratulations on your purchase of the FoodGUARD System. We are confident this system will provide you with years of fresh, clean and odor free air! UNPACKING/INSPECTION OF EQUIPMENT: Please be sure to inspect the equipment upon receipt for any possible shipping damage. -
Page 4: Operating Procedures
62-00532-0908 ELECTRICAL CONSIDERATIONS: The FoodGUARD unit is designed to operate using 120V, 60Hz, in accordance with the specifications of the National Electrical Code and for safety measures. The unit is shipped with a three wire blunt cord to be hardwired into a circuit. If required, a three-prong grounding plug can be attached to the unit for connection to a 120V, 60Hz outlet with a 5 amp minimum circuit breaker. -
Page 5: Removing The Cover
REMOVING THE COVER: 1. Remove cover retaining screws. 2. Remove cover. MOUNTING INSTRUCTIONS: 1. Screws (Anchors) should be placed in 2. Once unit hangs on screws, wall to allow keyhole slots to slide onto tighten screws down against unit. screws. - Page 6 MOUNTING INSTRUCTIONS (CONT.) 3. Attach L-brackets to unit. 4. Attach L-brackets to wall. 5. Install cover. 6. Secure cover with screws. 7. Connect wiring to suitable source for power requirements.
-
Page 7: Removing The Activepure® Retaining Plate
REMOVING THE ACTIVEPURE® CELLS' RETAINING PLATE: CAUTION: Unplug the unit before performing any maintenance procedures. 1. Remove cover retaining screws. 2. Remove cover. 3. Remove cells' retaining bracket screws 4. Remove cells' retaining bracket... -
Page 8: Removing The Activepure® Cells
REMOVING THE ACTIVEPURE® CELLS: 1. Each cell can be removed independently. To remove cell, pull cell straight out where the cell retaining bracket was located. Cells should be replaced annually to maintain optimum air purification. Cells can be swapped. For example - If only two cells (1, 2) are activated over the course of a year, then they could be swapped... -
Page 9: Installing The Activepure® Retaining Plate
INSTALLING THE ACTIVEPURE® CELLS' RETAINING PLATE: 1. Install cells' retaining bracket. 2. Secure cells' retaining bracket with screws. 3. Install cover 4. Secure cover with screws... -
Page 10: Changing The Filter
REPLACEMENT BULB: Part# ITEM US71129 FoodGUARD Replacement ActivePure® Cell Replace used cells annually. FCC STATEMENT AND USER INFORMATION This equipment has been tested and found to comply with the limits for Industrial, Scientific, and Medical Equipment (ISM), pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 11: Troubleshooting Guide
AOPs are dispersed throughout the room, greatly improves Does a fan or blower need to be left FoodGUARD's effectiveness. This air on in the treated area? movement helps to ensure the AOPs will come into contact with the contaminants to... -
Page 12: Warranty
WARRANTY INFORMATION LIMITED 3 YEAR WARRANTY Customer should not repackage and ship the FoodGUARD unit due to possibility of irreparable damage. For warranty service, please contact your activTek Distributor for the address of the nearest service center or call Customer Service at 866.736.0503.
