REPLACING THE ACTIVTEK
(CONTINUED)
4. Remove the two (2) thumb
screws holding the activTek
Cell Assembly.
7. Secure with two (2)
thumb screws.
NOTE: Always follow OSHA electrical lockout safety requirements to prevent accidental
release of energy during service or maintenance activities.
REPLACING THE BALLAST
WARNING
5. Remove the used activTek
Cell Assembly from the
base unit and dispose of
the cell properly.
8. Insert the Air Scrubber
Ozone by activTek
into the Duct
Mounting Plate.
Visit lamprecycle.org for proper bulb disposal regulations
•
UV Light in operation; disconnect unit from Power Cable before
servicing; failure to follow warnings may result in severe eye damage
•
Disconnect power at the breaker or fuse panel before
servicing unit; always follow OSHA lockout procedures to prevent
accidental exposure to electrical energy
CELL ASSEMBLY
®
9. Secure unit with four
+
(4) thumb nuts.
®
6. Plug the new activTek Cell
Assembly into the base unit.
Be sure Air Flow / Honeycomb
Cell direction is correct.
Power Cable
10.
Reconnect
Power Cable.
9
