DKV BOX EUROPE On Board Unit User Manual page 3

OBU Manual
List of Content
LIST OF CONTENT ................................................................................................................................... 3
LIST OF FIGURES ..................................................................................................................................... 5
1 TOLL CHARGING IN EETS DOMAINS ................................................................................................... 6
EETS in general ........................................................................................................................................ 6
EETS with DKV Euro Service .................................................................................................................... 6
2 PACKAGE CONTENT ........................................................................................................................... 8
3 INSTALLING THE OBU ........................................................................................................................ 9
Permanent installation ........................................................................................................................... 9
Flexible installation ............................................................................................................................... 10
Positioning the OBU on the windshield ................................................................................................ 11
Mounting the OBU on the windshield .................................................................................................. 12
Assemble the OBU to the holder .......................................................................................................... 12
4 QUICK START .................................................................................................................................. 13
Start Display .......................................................................................................................................... 13
Status Indication (LED) .......................................................................................................................... 14
First time usage of OBU ........................................................................................................................ 15
Requirements during driving ................................................................................................................ 15
Emergency procedure in case of malfunctions / defects at dedicated toll lanes................................. 15
Navigation through the Menu .............................................................................................................. 15
5 OBU SETTINGS AND TOLL DOMAIN SPECIFICS .................................................................................. 17
OBU Menu Structure ............................................................................................................................ 17
OBU Settings ......................................................................................................................................... 18
5.2.1 SELECT LANGUAGE
5.2.2 CHANGE NUMBER OF TRAILER AXLES
5.2.3 CHANGE CURRENT WEIGHT FOR TOLL SERVICE GERMANY (DEbag) AND POLAND (PLeto)
19
5.2.4 CONFIGURATION CHlsv
5.2.5 SHOW ACTIVATED TOLL SERVICES
5.2.6 VEHICLE PARAMETERS
5.2.7 VALUE ADDED SERVICES
5.2.8 SETTINGS
5.2.9 SHOW OBU INFORMATION AND SOFTWARE VERSIONS
5.2.10 SHOW NUMBER OF CUSTOMER SERVICE
6 TOLL SERVICE SPECIFICS .................................................................................................................. 26
Changeable OBU parameters (Overview) ............................................................................................. 26
Toll Lanes .............................................................................................................................................. 28
18
18
20
22
22
23
23
25
25
3
