DKV BOX EUROPE On Board Unit User Manual page 27

OBU Manual
Austria
ATasf
Bulgaria
BGria
France
FRtis
Spain
ESvia
Portugal
PTvve
Hungary
HUgo
Switzerland
CHlsv
Version 6.7, GM 4.8.1
Number of trailer axles
➢
Menu => Axles trailer
Number of trailer axles
➢
Menu => Axles trailer
Number of trailer axles
Menu => Axles trailer
Number of trailer axles
Menu => Axles trailer
Number of trailer axles
Menu => Axles trailer
Number of trailer axles
Menu => Axles trailer
Number of trailer axles
➢
Menu => Axles trailer
Current gross trailer
weight (GTW)
➢
Menu => Configuration
CHlsv => Trailer Weight
July 15, 2024
The OBU display shows the sum of tractor unit
axles + trailer axles.
Number of trailer axles must be updated if a
trailer is coupled or uncoupled to the tractor unit.
The OBU display shows the sum of tractor unit
axles + trailer axles.
Number of trailer axles must be updated if a
trailer is coupled or uncoupled to the tractor unit.
For Bulgaria, the maximum permissible gross
weight for the vehicle combination according to
the vehicle certificate is already stored in the
system during vehicle registration and is
automatically displayed on the OBU screen, e. g.
11.8t.
Number of trailer axles must be updated after
coupling or uncoupling a trailer to the tractor unit.
Number of axles is controlled in parallel by the Toll
Charger's roadside equipment.
Number of trailer axles should be updated after
coupling or uncoupling a trailer to the tractor unit.
Number of axles is determined in parallel by the
Toll Charger's roadside equipment.
Number of trailer axles should be updated after
coupling or uncoupling a trailer to the tractor unit.
Number of axles is determined in parallel by the
Toll Charger's roadside equipment.
The OBU display shows the sum of tractor unit
axles + trailer axles.
Number of trailer axles must be updated if a
trailer is coupled or uncoupled to the tractor unit.
Axles: the current, actual total number of axles for
the vehicle combination (tractor unit + trailer) is
displayed (here: "3"), which may differ depending
on the attached trailer. Therefore the trailer axles
must be specified separately by the driver via the
OBU.
Trailer Weight: The current gross trailer weight
must be updated, when attaching a trailer to the
tractor unit. The current gross trailer weight (GTW)
is the maximum permissible weight of the
currently attached trailer. The start screen shows
the total weight.
27
