Hardware Installation and Reference Guide
Appendix
The following figure shows feasible connections of the straight-through and crossover twisted pair cables for a
100BASE-TX/10BASE-T port.
Figure 7-2
100BASE-TX/10BASE-T Twisted Pair Connections
St raight -Through
Cr ossover
Switch
Adapter
Switch
Switch
23
