Warning
Operation of this equipment in a residential environment could cause radio interference.
Note
The weight refers to the weight of the main unit.
1.5 Power Supply Technical Specifications
The RG-EST450G can be powered by 12 V/1.2 A DC power supply, 24 V passive PoE power supply, and IEEE
802.3at/af-compliant PoE power supply. It is supplied with a 24 V/0.6 A DC power adapter and a 1000 Mbps
passive PoE injector.

Technical specifications of the DC adapter:
Inner Diameter
2.10 mm ± 0.05 mm
(0.083 in. ± 0.002 in.)
Warning

For DC power supply, the DC adapter required for this wireless bridge is not included in the package. You
can purchase the DC adapter separately from us.

For PoE power supply, use the provided PoE injector in the package. Do not use other models of PoE
injectors or switches for power supply as it may lead to irreparable damage to the device.

When using a DC power supply to power the device, ensure that the power output of the DC power
supply is less than 100 W.
Outer Diameter
5.50 mm ± 0.05 mm
(0.22 in. ± 0.002 in.)
8
Product Introduction
Depth
10 mm (0.35 in.)
