Installation Guide
3.3 Safety Precautions During Installation
To ensure minimal interference when installing multiple wireless bridges in close proximity, maintain a horizontal
installation distance of at least 2 meters (6.56 ft), or a vertical installation distance of at least 0.5 meters (1.64 ft)
between each wireless bridge. Ensure that the horizontal angle formed by the two wireless bridges is greater
than 120 degrees. The specific installation location of the wireless bridge should be determined by professionals
after conducting a thorough site survey.
Before installation, ensure that the installation location meets the requirements in
Requirements, and pay attention to the following:

Use the supplied 24 V/0.6 A DC power adapter or an equivalent power source with the same specifications
to power the equipment. Do not use adapters with different specifications.

When the equipment is powered by 24 V passive PoE and is operating under full load (with simultaneous 2.4
GHz, 5 GHz, and wired connectivity), the maximum recommended cable length for the Cat5e cable is 80 m
(262.47 ft.).

Ensure that the Ethernet cable and power cord are securely connected.
3.4 Mounting the Device
Caution

Install the device in a manner that maximizes the coverage area of the antenna.

The schematic diagram provided is for reference purposes only. The actual product should be installed
based on its physical specifications and design.
3.4.1 Wall Mounting
(1) Secure the mounting bracket on the wall.
(2) Install the device to the mounting bracket.
(3) Adjust the orientation.
