Ruijie Reyee RG-EST450G Installation Manual page 13

Installation Guide
Model
Data Rate
Modulation
Technology
Receive Sensitivity
Max. Transmit Power
Power Step
Dimensions (W x D x
H)
Weight
Service Ports
Buttons
LED
Power Supply
Max. Power
Consumption
Environment
Mounting
IP Rating
Certification
MTBF
RG-EST450G
2.4 GHz: 150 Mbps
5 GHz: 867 Mbps
OFDM: BPSK@6/9 Mbps, QPSK@12/18 Mbps, 16-QAM@24/36 Mbps,
64-QAM@48/54 Mbps
MIMO-OFDM: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
11a: -89 dBm (6 Mbps), –80 dBm (24 Mbps), –76 dBm (36 Mbps), –
71dBm (54 Mbps)
11n: –83 dBm@MCS0, –65 dBm@MCS7, –83 dBm@MCS8, –
65dBm@MCS15
11ac: –86 dBm (MCS0), –63 dBm (MCS9)
2.4 GHz: 100 mW
5 GHz: 400 mW (26 dBm) (single stream)
1 dBm
355 mm x 124 mm x 48 mm (13.98 in. x 4.88 in. x 1.89 in.) (excluding the
mounting bracket)
0.83 kg (1.83 lbs.) (excluding
1.61 kg (3.55 lbs.) (including
3 x 10/100/1000BASE-T auto-negotiation ports, where LAN1/PoE port supports
24 V PoE input
1 x Reset/One-Touch Pairing button
1 x system LED, 3 x port LEDs, and 3 x signal LEDs
24 V passive PoE power supply (A passive PoE injector is delivered with
the wireless bridge.)
12 V DC (solar panel)
< 12 W
Operating temperature: –30° C to +65° C (–22° F to +149° F)
Storage temperature: –40° C to +85° C (–40° F to +185° F)
Operating humidity: 5% RH to 95% RH (non-condensing)
Storage humidity: 5% RH to 95% RH (non-condensing)
Wall-mount
Pole-mount
IP55
CE
> 400000 hours
7
packaging materials)
packaging materials)
Product Introduction
