OPERATING INSTRUCTIONS
5.1 Notes on UL approval
6 Commissioning
6.1 Alignment
en
30 O P E R A T I N G I N S T R U C T I O N S | RAY10
UL Environmental Rating: Enclosure type 1
Alignment
NOTE
Tip: Use the signal strength light bar on the back of the sensor to help you align it
correctly.
Figure 5: Alignment
