RT-3016A
Fanless Touch POS Terminal
User Manual
FCC NOTES
This system meets industry & government requirements and applicable standards. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions manual, may cause interference to radio
communications. It has been tested and found to comply with limits for a Class A digital
device pursuant to subpart B of Part 15 of FCC Rules, which are designed to provide
reasonable protection against interference when operated in a commercial environment.
Operation of this equipment in a residential area is likely to cause interference in which case
the user at his own expense will be required to take whatever measures to correct the
interference.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
CE CLASS A WARNING
This equipment is compliant with Class A of CISPR 32. In a residential environment this
equipment may cause radio interference.
AVERTISSEMENT CE CLASSE A
Cet équipement est conforme à la classe A de CISPR 32. Dans un environnement résidentiel,
cet équipement peut provoquer des interférences radio.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than the
authorized technicians. The user should consult his/her dealer for the problem happening.
Warranty voids if the user does not follow the instructions in application of this merchandise. The
manufacturer is by no means responsible for any damage or hazard caused by improper application.
LIMITES DE GARANTIE
La garantie prend fin automatiquement lorsque la machine est ouverte par une personne autre que
les techniciens autorisés. L'utilisateur doit consulter son revendeur pour le problème qui se produit.
La garantie s'annule si l'utilisateur ne suit pas les instructions d'application de cette marchandise.
Le fabricant n'est en aucun cas responsable de tout dommage ou danger causé par une mauvaise
application.
警告使用者
為避免電磁干擾,本產品不應安裝或使用於住宅環境。
RT-3016A Ver. A0
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RT-3016A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for POSIFLEX RT-3016A

  • Page 1 L'utilisateur doit consulter son revendeur pour le problème qui se produit. La garantie s'annule si l'utilisateur ne suit pas les instructions d'application de cette marchandise. Le fabricant n'est en aucun cas responsable de tout dommage ou danger causé par une mauvaise application. 警告使用者 為避免電磁干擾,本產品不應安裝或使用於住宅環境。 RT-3016A Ver. A0...
  • Page 2 SAFETY INSTRUCTIONS This equipment is not suitable for use in locations where children are likely to be present. CONSIGNES DE SÉ CURITÉ Cet équipement ne convient pas à une utilisation dans des lieux pouvant accueillir des enfants. WARNING Power cord shall be connected to a socket-outlet with earthing connection. ATTENTION Le cordon d'alimentation doit être connecté...
  • Page 3: Revision History

    Revision History Date Version Description 2025/04/24 For Preliminary Release Package Contents  RT-3016A 15.6” fanless touch terminal (x 1)  Power adapter (x 1)  Power cord (x 1) Views of RT-3016A Front View Camera (Optional) P-Cap Touch Panel LED indicator...
  • Page 4 System Back Cover Release Lever for System Back Cover Left-Side View Power Button Brightness Adjustment Button + Brightness Adjustment Button - View of I/O Interface of RT-3016A Bottom Side View LAN Port CR Port RJ50 COM Port Switch for USB OTG Port...
  • Page 5: Inside View

    When the switch is switched to the side with the printed word “Host” on it, all I/O ports are working normally. Note: Please use the type-C cable certified/provided by Posiflex. Please DO NOT use the cables from other unknown sources.
  • Page 6 Positioning your POS for a Perfect Viewing Angle Steady the base with one hand, and then tilt the screen in the direction shown by the arrow in the figure. Please do NOT press on the LCD panel while setting up the tilt angle. Installing Power Adapter and Cables The following provides instructions required to install your cables.
  • Page 7 To remove the stand cover from the base, please slide it in the horizontal direction shown by the arrow. Connect the connector of the power adapter to the DC-IN power jack. If necessary, properly insert other cables into the correct port.
  • Page 8 Place back the sytem back cover. Make sure it is well locked into place with a click sound. For the fire-resistant system back cover, please insert another screw into the screw hole indicated in the figure, and secure it. Screw for Fire-Resistant System Back Cover Make sure the cable could be pulled out of the cable exit from the bottom of the base.
  • Page 9 Installing Optional Upgrade Kits and Peripherals RT-3016A is an expandable model which allows you to upgrade its own capacity by additionally installing multiple peripheral devices, such as magnetic stripe reader (MSR), fingerprint or iButton sensors, and 2 rear- mount POS monitor, according to your preference. The following will give you brief instructions on how to expand on your current POS system with these optional upgrade kits.
  • Page 10 Hold down the release lever at the bottom of the system back cover and then pulling the cover outwards To remove the stand cover from the base, please slide it in the horizontal direction shown by the arrow. For GT-470, the cable can be connected after installation. For GT-570, please connect the 5-pin USB cable and 6-pin power cable to the GT-570 module before installing the module.
  • Page 11 The installation steps are the same for GT-470 and GT-570. The following installation steps take GT-470 as an example. 4.1 Align the two screw bolts at the bottom of PoweredUSB or USB hub with rail slots in the base. 4.2 Push PoweredUSB or USB hub in the direction shown by the arrow to lock it into place.
  • Page 12 Install power adaptor extension cable, USB cable, and power adaptor for GT-470. Insert one end of the provided power adaptor extension cable to DC Input port of PoweredUSB hub and another end to DC- in power jack of the terminal. Insert mini-USB connector of the USB cable to PoweredUSB hub and another end to USB3.0 port of the terminal.
  • Page 13: Status Led Indicator

    10 seconds to force a shutdown of the system. Operation Environment To prevent RT-3016A from overheating, it is suggested to position your terminal in a well-ventilated working environment. In doing so, please be...
  • Page 14: Specifications

    POS terminal at least 25mm away from other devices to ensure the machine is properly cooled down and functioning normally. Specifications RT-3016A MTK Genio G700 (MT8390, 2+6 A78/A55) System Memory 8GB onboard 128GB eMMC onboard + 1 x micro SD slot...
  • Page 15: Outline Dimension

    Outline Dimension ※ The product information and specifications are subject to change without prior notice. To get the detailed information on the RT-3016A, please check this model from Posiflex Global Website. Manufacturer: Posiflex Technology Inc. 4F-8F, No. 23, Datong St., Tucheng Dist., New Taipei City 236044, Taiwan Tel : +886 2 2268 5577 製造商資訊...
