RT-5015E/5016E/5115E/5116E/
RT-5015Q/5016Q/5115Q/5116Q
Fanless Touch POS Terminal
User Manual
16940903040 Ver. D0
http://www.posiflex.com
Package Contents
RT-5015E/Q 15" fanless touch terminal or
RT-5016E/Q 15.6" fanless touch terminal or
RT-5115E/Q 15" fanless touch terminal or
RT-5116E/Q 15.6" fanless touch terminal..x1
Power adapter...................................x1
Power cord.......................................x1
User manual.....................................x1
Screw for back cover...........................x1
1
Advertisement
Related Manuals for POSIFLEX RT-5015E
Summary of Contents for POSIFLEX RT-5015E
- Page 1 RT-5015E/5016E/5115E/5116E/ RT-5015Q/5016Q/5115Q/5116Q Fanless Touch POS Terminal User Manual Package Contents RT-5015E/Q 15” fanless touch terminal or RT-5016E/Q 15.6” fanless touch terminal or RT-5115E/Q 15” fanless touch terminal or RT-5116E/Q 15.6” fanless touch terminal..x1 Power adapter……………………………..x1 Power cord………………………………...x1 ...
- Page 2 SOME IMPORTANT NOTES FCC NOTES This system meets industry & government requirements and applicable standards. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions manual, may cause interference to radio communications. It has been tested and found to comply with limits for a Class A digital device pursuant to subpart B of Part 15 of FCC Rules, which are designed to provide reasonable protection against interference when operated in a commercial environment.
- Page 3 警告使用者 這是甲類的資訊產品，在居住的環境中使用時，可能會造成射頻干擾， 在這種情況下，使用者會被要求採取某些適當的對策。 BATTERY CAUTION NOTES Dispose of used batteries according to the instructions. Replacement of a battery with an incorrect type that can defeat a safeguard (for example, in the case of some lithium battery types) Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery that can result in an explosion.
- Page 4 Views of RT-5XXXE/Q Front View Camera (Optional) P-Cap Touch Panel LED indicator LED indicator 15” RT-5015E/5115E/5015Q/5115Q 15.6” RT-5016E/5116E/5016Q/5116Q Rear View Thumbscrew for VESA Mount Bracket System Back Cover Attachment Bay Pole Mount Screw Hole Bottom View Screw Hole Release Lever for System Back Cover...
- Page 5 Right-Side View Power Button Brightness Adjustment Button ＋ Brightness Adjustment Button － Left-Side View Rubber Shield for USB2.0 Port View of I/O Interface of RT-5XXXE/Q Left Side USB 2.0 Port...
- Page 6 Bottom Side DB9 COM Port CR Port LAN Port USB 3.0 Ports RJ50 COM Ports 24V PoweredUSB Port Mini DisplayPort DC IN Power Connector Connecting Power Adapter and Cables The following provides instructions required to connect your cables. 1. To remove the back cover, hold down the release levers at the bottom of the system back cover and then pulling the cover outwards.
- Page 7 4. Place back the sytem back cover. Make sure it is well locked into place with a click sound. 5. Make sure the cable could be pulled out of the cable exit from the bottom of the base. 6. Please insert another screw into the screw hole indicated in the figure, and secure it.
- Page 8 Adjustment for VESA Mount Bracket There are two thumbscrews on the VESA mount bracket. Loosen the two thumbscrews. After loosening the thumbscrews, you can carefully move the monitor downward around 45° to do the service. To close the VESA mount bracket, please gently move the monitor back and then fasten the two thumbscrews.
-
Page 9: Installing An Operating System
LED status indicator, which is located at the bottom edge of the LCD panel, is mainly responsible for notifying users of the current system status by emitting various LED signals. In the chart provided below, it describes all the possible LED status as a quick reference. 15” RT-5015E/5115E/5015Q/5116Q LED Status Description System power OFF... -
Page 10: Operation Environment
POS terminal at least 25mm away from other devices to ensure the machine is properly cooled down and functioning normally. Driver Download If your POS terminal is shipped without OS pre-installed, please download the relevant driver that you need from the Posiflex website (http://www.posiflex.com/en-global/Download/download). Specifications RT-5015E/5016E/5015Q/5016Q... - Page 11 M.2 slot x 1 Extension Slot 368 x 292 x 46.6 Dimension (W x V x D in mm) Operating： 0°C 〜 40°C, 20%RH - 90%RH Environmental Requirements Storage： -20°C 〜 60°C, 10%RH - 90%RH FCC/CE Regulation Rules Attachment Slim MSR attachment for RT series RA-101 RA-103 iButton (or RFID) with one USB port attachment...
- Page 12 RT-560 USB port replicator (USB2.0 x 4, installed in base stand) ※ The product information and specifications are subject to change without prior notice. To get the detailed information on the RT-5XXXE/Q, please check this model from Posiflex Global Website.
