RA-301/311/305/307
Side Attachment for RT-series Terminals
User Manual
FCC NOTES
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
CE CLASS A WARNING
This equipment is compliant with Class A of CISPR 32. In a residential environment this
equipment may cause radio interference.
AVERTISSEMENT CE CLASSE A
Cet équipement est conforme à la classe A de CISPR 32. Dans un environnement résidentiel, cet
équipement peut provoquer des interférences radio.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than the
authorized technicians. The user should consult his/her dealer for the problem happening.
Warranty voids if the user does not follow the instructions in application of this merchandise. The
manufacturer is by no means responsible for any damage or hazard caused by improper application.
LIMITES DE GARANTIE
La garantie prend fin automatiquement lorsque la machine est ouverte par une personne autre que
les techniciens autorisés. L'utilisateur doit consulter son revendeur pour le problème qui se produit.
La garantie s'annule si l'utilisateur ne suit pas les instructions d'application de cette marchandise.
Le fabricant n'est en aucun cas responsable de tout dommage ou danger causé par une mauvaise
application.
警告
為避免電磁干擾,本產品不應安裝或使用於住宅環境。
SAFETY INSTRUCTIONS
This equipment is not suitable for use in locations where children are likely to be present.
CONSIGNES DE SÉ CURITÉ
Cet équipement ne convient pas à une utilisation dans des lieux pouvant accueillir des
enfants.
RA-3xx Series Ver. C0
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the RA-301 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for POSIFLEX RA-301

  • Page 1 RA-301/311/305/307 Side Attachment for RT-series Terminals User Manual FCC NOTES This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 2 RA-301 (MSR / 2D Imager / Fingerprint) Package Contents  RA-301 Side Attachment……………………(1)  Back Cover…………………………………..(1)  Fixing Screw (M3)…………….…………….(2)  2D Imager Quick Setup Guide………………(1) (For attachment with 2D scanner) RA-311 (MSR / 2D Imager / RFID) Package Contents ...
  • Page 3 Views of the RA-301 Screws Holes Fingerprint Sensor with Status LED Indicator USB I/O Cable (Optional) Scan Window w/ Object Detector (Optional) 3-track Magnetic Stripe Reader (Optional) Views of the RA-311 Screws Holes RFID Card Reader (Optional) USB I/O Cable...
  • Page 4 Views of the RA-307-15 RFID Reader (Optional) USB I/O Cable 3-track Magnetic Stripe Reader FingerPrint Sensor (Optional) Installing RA-3xx Series to RT-series Terminals 1. Use slotted screwdriver to remove the cover for attachment bay which is located on the left side of the rear of your RT-series terminal. 2.
  • Page 5 3. Align the screw holes of RA-3xx series with the mounting holes inside the attachment bay of your RT-series terminal, and then secure RA-3xx series with two screws. RA-301/311 RA-305/307 (Only for RT-15” model) 4. Push the excess cable to the inside.
  • Page 6 Before installing the drivers of the RA series attachment, after installing the RA series attachment, power on your RT-series terminal. Installing and Starting the Posiflex USB MSR Manager Before installing the USB MSR Manager, please visit Posiflex official website (https://download.posiflex.com/en- global/Download/index/driver/Attachment/RA-301) to download the utility.
  • Page 7 8. After completion of the driver installation, restart your terminal. Installing the RFID Setup Tool If you purchase the attachment having the RFID module of which the interface is Virtual COM, please visit Posiflex official website (https://download.posiflex.com/en- global/Download/index/driver/Attachment/RA-301) to download the virtual COM driver.
  • Page 8 Please visit Posiflex Global Website (https://download.posiflex.com/en-global/Download/index) to download the related documents.
  • Page 9 2D Imager To enhance your experience using 2D imager, the RA-301/311 provide a wide range of angle adjustment, with a vertical scanning angle of up to 110˚ and horizontal scanning angle of up to 180˚. Please refer to the figures below to properly adjust the 2D imager for a better scanning angle.
  • Page 10 60~240mm (Resolution(0.25)) 80~260mm (Resolution(0.33))  Code 128 65~210mm (Resolution(0.25))  UPC 45~300mm (Resolution(0.33)) Depth of field (mm)  PDF417 30~210mm (Resolution(0.25))  QR Code 30~240mm (Resolution(0.381))  DataMatrix 35~160mm (Resolution(0.31)) (Measured from the front end of the scanner) Outline Dimension RA-301...
  • Page 11 RA-311...
  • Page 12 RA-305-15 RA-307-15...
  • Page 13 BSMI ROHS RA-301/311/305-15/307-15 ※ The product information and specifications are subject to change without prior notice.
