Jiva KS-6615 /
KS-6617 SERIES
TECHNICAL MANUAL
Rev. : Original
POSIFLEX TECHNOLOGIES, INC.
ISO-14001
AND
http://www.posiflex.com
http://www.posiflexusa.com
CERTIFIED MANUFACTURER
http://www.posiflex.com.tw
EMAIL: posiflex@posiflex.com.tw
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for POSIFLEX Jiva KS-6615 Series
Summary of Contents for POSIFLEX Jiva KS-6615 Series
- Page 1 Jiva KS-6615 / KS-6617 SERIES TECHNICAL MANUAL Rev. : Original POSIFLEX TECHNOLOGIES, INC. MANUFACTURED BY: ISO-9001 ISO-14001 CERTIFIED MANUFACTURER 6,WU-CHUAN RD.,HSIN-CHUANG TEL: 886-2-2991599 (REP.) FAX: 886-2-2991819, 2991808 (WU-KU INDUSTRIAL ZONE) http://www.posiflex.com http://www.posiflex.com.tw TAIPEI HSIEN, TAIWAN http://www.posiflexusa.com EMAIL: posiflex@posiflex.com.tw...
- Page 2 This manual assists the user especially the software programmer who provides the software system for POS application to utilize the hardware of the Jiva KS series which is a member of the POSIFLEX integrated point-of-sale terminal product family. The Jiva KS is a compact point-of-sale...
-
Page 3: Table Of Contents
TABLE OF CONTENTS OVERVIEW ..........1 - 1 SCOPE . - Page 4 UPS BATTERY ....... . . 2 - 7 CF CARD CONNECTOR ......2 - 8 CASH DRAWER CONTROL CABLE .
- Page 5 POWER SUPPLY TO COM PORTS ..... 5 - 1 CUSTOMER DISPLAY ....... . 5 - 1 COM1 APPLICATION COMMENT .
- Page 6 ....5 - 13 MSR TRACK 3 LEADING CODE ......5 - 13 MSR ENDING CODE .
- Page 7 COMPONENT SIDE ......6 - 8 SOLDER SIDE ....... . . 6 - 8 CONNECTORS .
- Page 8 ASSEMBLY DRAWING ....... 7 - 14...
-
Page 9: Overview
OVERVIEW SCOPE The Jiva KS-6615 / KS-6617 series is a series of fully integrated PC based Point-Of-Sale terminals. This series provides excellent performance for Point-Of-Sale, Hospitality and Kiosk systems with a Celeron CPU of Mobile 1.5 GHz in 479-ball Micro-FCBGA package with Intel 910GMLE + ICH6M chipset inside an Aluminum alloy enclosure without any exhaust fan. - Page 10 4 serial ports with DB9 connectors, each with capability for +5V DC power support b. 1 parallel port 6 USB ports (4 in I/O area and 2 in side cover for instant service use) d. 1 proprietary USB port for side mount kit such as SD-400T 1 LAN port 100 Base-TX / 1000 base-T Ethernet 1 external VGA monitor port g.
-
Page 11: Optional Items
OPTIONAL ITEMS Note: The “∗” marked items in the following list means that option must be set prior to shipment from the factory. The rest items can be set by the dealers. a) *Optional model to be without touch panel or with IR touch panel b) 2 HDD or CF memory card reader c) DDR2 SODIMM memory expansion up to 1 GB max. -
Page 13: General Specifications
GENERAL SPECIFICATION SYSTEM l CPU: Intel Celeron M 1.5 GHz (1 MB L2 cache) l DDR2 SODIMM : 512 MB (expandable to 1GB) l Built-in 2.5” SATA interface HDD 40 GB above in base POWER SOURCE Item Specification Voltage range of adaptor input 100 ~ 240 V AC Load limit of adaptor input 2.5 A max. -
Page 14: Ups Support (Battery Option)
UPS SUPPORT (battery option) l Supports system operation for up to 30 min. depending on loading condition l LED panel turns on green when adaptor power stand-by l LED panel flashes in blue and system beeps when UPS battery starts working and discharging, and LED panel flashes rapidly when UPS near to l Working on UPS battery status can be detected through COM1 status port 12VDC POWER SUPPLY INTO SYSTEM... -
Page 15: Hdd In Base
l 1 x 4 pin 12 V DC power input jack l 1 x UPS connector for 2.3AH/12V or above Lead Acid battery l 1 x internal SATA port for optional HDD in main unit HDD IN BASE l 40 GB or above operating up to SATA 1 (150 MB/s) TOUCH PANEL l Extremely endurable life survives minimum 35,000,000 touches at same spot... -
Page 16: Audio Port
AUDIO PORT l 3.5 Ø mono jack for Mic. In l 3.5 Ø stereo jack for audio line out l Output audio power 2.0 W x 2 (in stereo signal to internal speakers in back cover) l Bandwidth 350 Hz ~ 12 KHz LED MODULE COLOR l Type: blue/green dual color (blue for power on;... -
Page 17: Environmental
ENVIRONMENTAL l TEMPERATURE RANGE (excl. UPS battery): Operating: 0°C ~ +40°C or 32°F ~ 104°F Non-operating: -20°C ~ +60°C or -4°F ~ +140°F l TEMPERATURE RANGE for UPS battery: Operating: 0°C ~ +40°C or 32°F ~ 104°F Non-operating: -20°C ~ +40°C or -4°F ~ +104°F l HUMIDITY RANGE: Operating: 20%RH ~ 80%RH, non-condensing, max. -
Page 18: Options
OPTIONS SECOND DISPLAY ON REAR BASE Model Number LM6101 LM6201 COLOR TFT 12.1” Display Type Interface 245.8 X 184.3 mm 246 X 184.5 mm View area 175 cd/m 400 cd/m Luminance CCFL x 1 CCFL x 2 Backlight 500 : 1 500 : 1 Contrast Ratio 1024 X 768 (XGA) -
Page 19: Dram Expansion
157.05 x Display area (mm x mm) 193 x 39 142.8 x 20.64 22.86 260 x 65 x 197 x 56 x 217 x 80.5 x 196.7 x 57.5 Display head size (mm) 28.5 x 39.6 Mounting method Pole mount on base Base mount Pole on base Pole height (mm) N. -
Page 20: Cf Card Connector
CF CARD CONNECTOR l Accepts Compact Flash Memory Card type II l Occupies IDE primary channel CASH DRAWER CONTROL CABLE l 2 in 1 cash drawer control cable 20863023800 for independent control over two cash drawers of CR3100 or CR3200 or CR4000 2.5”... -
Page 21: Pp-7000Ii / Pp-7000L / Pp-7000U
PP-5700 1. Dot matrix 9 pin 2. Bi-directional printing 3. Sprocket feed type 4. 2 models for single pass or double pass print of Chinese characters 5. 4.4 lines per second for single pass or 2.2 lines per second for double pass print 6. -
Page 23: Reliability Specification
RELIABILITY SPECIFICATION l POWER ADAPTOR MTBF: 50,000 HRS l TOUCH PANEL LIFE EXPECTANCY (TOUCHES AT SAME SPOT): IR TYPE: 50,000,000 UP RESISTIVE TYPE: 35,000,000 UP l LCD PANEL LIFE EXPECTANCY: 40,000 HRS FOR TFT l HDD LOAD/UNLOAD CYLES: 300,000 TIMES l HDD MTBF: 50,000 HRS l CD ROM DRIVE MTBF: 120,000 POH (10% duty cycle, seek and read) - Page 24 l MSR LIFE EXPECTANCY: 500,000 PASSES l MOTHER BOARD MTBF: 50,000 HOURS l POWER SWITCH LIFE EXPECTANCY: 50,000 STROKES l EXTERNAL FDD MTBF: 80,000 HRS KS-6615 / KS-6617 series Technical Manual 3 - 2...
-
Page 25: System Definitions
SYSTEM DEFINITIONS 15” LCD 17” LCD Resistive IR touch Inverter BLOCK DIAGRAM panel panel touch panel panel LVDS SDVO RS232 IR RS232 Micro Inverter (COM5) Brightness COM4 connector adaptor Touch Touch Device controller connector (+5V) Adjust Buttons controller controller (Shared with SDVO RS232... -
Page 26: 12 V Dc In Connector
12 V DC IN CONNECTOR PIN ASSIGNMENT OF 4 PIN PLUG: PIN # DEFINITION +12 V +12 V CASE CASE CHASSIS GND USB0 ~ USB5 PIN ASSIGNMENT OF EACH 4 PIN JACK: PIN # DEFINITION -DATA +DATA PIN 1 LAN PORT PIN ASSIGNMENT OF 8 PIN TELEPHONE JACK: PIN # DEFINITION PIN 1... -
Page 27: Ups Battery Connector
UPS BATTERY CONNECTOR PIN ASSIGNMENT OF 4 PIN SOCKET: PIN # DEFINITION +12 V PIN 1 +12 V SERIAL PORT COM1 PIN ASSIGNMENT OF MALE DB9 – 10 pin RJ45 CONVERSION CABLE: DB9 PIN # PIN DEFINITION ALTERNATIVE DEF. DEFAULT SETTING CHASSIS BATTWK BATTWK... -
Page 28: Serial Port Com2/3/4
SERIAL PORT COM2/3/4 PIN ASSIGNMENT OF MALE DB9 – 10 pin RJ45 CONVERSION CABLE: DB9 PIN # PIN DEFINITION ALTERNATIVE DEF. DEFAULT SETTING CHASSIS +5 VDC • IRQ 3, 10, 5 are assigned for COM2/3/4 • DC supply to these ports is UPS supported. •... -
Page 29: Parallel Port Lpt1
PARALLEL PORT LPT1 PIN ASSIGNMENT OF 25 PIN D SUB FEMALE CONNECTOR: PIN # SPP MODE EPP MODE ECP MODE - STROBE -WRITE -STROBE - ACK INTR -ACK BUSY -WAIT BUSY, PeriphAck Perror, -AckReverse SLCT SLCT - AUTO FEED -Datastb -AutoFeed, HostAck - ERROR -Fault, -PeriphRequest... -
Page 30: Vga Connector
VGA CONNECTOR l This port is a standard 3 x 5 D-sub VGA connector PIN # DEFINITION PIN # DEFINITION PIN # DEFINITION NCID0 GREEN NCID1 BLUE HSYNC NCID2 NC/+12VKEY VSYNC NCID3 SATA CONNECTOR l This connector is a single deck SATA connector PIN ASSIGNMENT OF EACH 7 PIN CONTACTS: PIN # DEFINITION... -
Page 31: Application Guides
JP3 determines +12V DC supply to VGA port. Refer to the hardware details for jumper settings. The load supplied from the Jiva KS-66 series to all USB devices on 5 V DC is limited to be within 0.5 Ampere for each port, and power on 5 V DC to all COM ports is limited to be within 1 Ampere. -
Page 32: Cash Drawer
status and could halt this port if COM 1 is not connected properly. Any possible cross- link to the command for power manager that is also using COM1 at 9600bps, none parity, 8 data bits, 1 stop bit should be avoided. An index summary of such commands is tabulated at end of this chapter. -
Page 33: System Bios Update
SYSTEM BIOS UPDATE SPILOAE.EXE Unlike usual personal computers, the update of system BIOS for this highly professional equipment should never be carried out unless notified by the central technical department of Posiflex. Even in such circumstances, please always check the system revision of the equipment for the correct utility program to do the update as the required utility may be different for each system revision not to mention being different to so called “similar product”. -
Page 34: Power On/Off Control
POWER ON/OFF CONTROL EXTERNAL POWER SWITCH Whenever the Jiva KS series is to be powered on for the first time after connected to external AC power, this switch must be engaged to turn on the power. This switch is originally an “ON/OFF” power switch. It can be programmed into a power “ON”... -
Page 35: Ups Battery
that case the programmer has to program the command to close the application programs (just like “Alt+F4” in Windows), and then at the end of the closing operation, the application program should issue the above mentioned software switch off command string to COM1 under the protocol: 9600 bps, parity none, 8 data bits, 1 stop bit. -
Page 36: Ups Status Detect Functions
UPS function will be automatically enabled or disabled depending on the existence of a healthy UPS battery. In the Jiva KS series products, when the system is working on UPS battery power, the status is indicated by LED and is detectable by software. This “operating on battery”... - Page 37 is not recommended to be used on COM1). When the system is working on AC power, the DCD signal of COM1 is reset (value = 0). When the system is working on battery power, the DCD signal of COM1 (BATTWK signal) is set (value = 1). The DCD signal is obtained as the bit 7 (the most significant bit) of the I/O address 3FEh if the COM1 address is set to 3F8h~3FFh (conventional address for COM1) in system configuration.
-
Page 38: Automatic Power On Control
AUTOMATIC POWER ON CONTROL When the system is turned off after a successful boot up, the preset automatic power on functions if set as below will keep monitoring for the preset conditions and turn on the system when the preset conditions are met. Please note that if the system is improperly turned off before a complete boot up procedure, the mentioned preset power on control functions will be disabled until next turning off after a complete boot up. -
Page 39: Fingerprint Sensor
\Drivers\KS661X\LAN_xxx and execute this file on the target machine. Select the item “View Current Configuration” in the Main Menu and write down the 6 2-digit numbers of the item “Ethernet Address:” for the network technician. Then the target machine should be powered off in a normal way with AC power supply and LAN connections. Now the networking technician at the master machine can execute the same file “RSET8168.EXE”... -
Page 40: Posiflex Tools
POSIFLEX TOOLS In the preinstalled OS there will be a program group named “POSIFLEX Tools” for specific Posiflex device(s) installed. POSIFLEX POWER SWITCH MANAGER The power switch manager determines the UPS control and function of the hardware power switch that is in side cover of the machine. -
Page 41: Power Switch Setting
POWER SWITCH SETTING The function of the power switch that is at side of the machine can be defined here. When “ON/OFF” function for this switch is selected, the power switch turns the system on when the system is off and turns the system off when the system is on. When “ON Only”... -
Page 42: Posiflex Usb Msr Manager
POSIFLEX USB MSR MANAGER For systems with USB MSR on SD-400T kit, the USB MSR manager helps defining several characteristics in output format control for reading the magnetic stripe card. Please find the subfolder \Drivers\SD Series\USBMSR_xxx in Posiflex product information CD and execute the “SETUP.EXE” to install the USB MSR Manager. The screen shot of the program is similar to the picture at right as below. -
Page 43: Enable Msr Track 1
“Alt” key while pressing “6” and “5” keys of the numerical keypad consecutively are sent to the keyboard controller. Therefore, the data will not be misinterpreted regardless of the keyboard layout. ENABLE MSR TRACK 1 A tick in the check box enables the reading of track 1 data if the reader head for track 1 exists. -
Page 44: Transmission Intercharacter Delay
TRANSMISSION INTERCHARACTER DELAY Usually, the processing algorithm and the keyboard data input buffer in an operating system are arranged in such a way that the system resources are preserved as much as possible while data input from the keyboard port presents no problem. However, as we know that the amount of data read from one single swipe of MSR can be very much larger than any possibly fastest keyboard entry in same duration. -
Page 45: Posiflex Usb Touch Manager
POSIFLEX USB TOUCH MANAGER When the touch control panel installed is the resistive type panel and the touch control interface used is USB interface, “Posiflex Touch Manager” will be installed with the preloaded OS and there will be 4 utilities in the “Posiflex USB Touch Tools”... -
Page 46: Usb Touch Calibrator
Enable PIR – This check box is not applicable to the monitor. Please keep it unchecked. Enable Touch – This check box must be checked to have the touch panel working. Touch as Right Button Click – This check box defines each touch on touch panel as clicking the right button of mouse at that point. -
Page 47: Usb Touch Edge Acceleration Tool
USB TOUCH EDGE ACCELERATION TOOL This program helps to find the hidden taskbar or thin scroll bar through touch. Enable ... – Each check box determines whether or not to engage edge acceleration against which edge of screen. Margin – This list button selects the range to engage edge acceleration toward the edge before the edge is reached. -
Page 48: Rs232 Touch Driver
RS232 TOUCH DRIVER The touch control driver for the IR type touch panel used in this product series utilizing RS232 interface can also be used for the normal optional resistive type touch panel of this product series. Please find the subfolder \Drivers\KS631X\TOUCH\IR in the Posiflex Product Information CD and study the “readme”... - Page 49 The “Align” button starts calibration process that requires the user to click on 3 marks appeared consecutively. The size selected for “Double- click area” sets the precision definition of the simulated mouse click for the screen touch. When the value is set too large, the mouse pointer would appear to be off from the point touched.
-
Page 50: Software Command Index
SOFTWARE COMMAND INDEX Following table is a collection of software command applicable to the Jiva KS series for a quick look up. The page number listed could deviate from the display of this file if different viewer is utilized. Usage of the Command... -
Page 51: Hardware Details
HARDWARE DETAILS MAIN BOARD (KS-6615A) COMPONENT SIDE Notation Remarks: 1. A small black block in the drawing for a jumper or an IC is used to indicate the position of pin number 1. JP12 2. A small number “1” or JP13 “2”... -
Page 52: Solder Side
SOLDER SIDE JP11 JP10 Service window details Notation Remarks: 1. A small black block in the drawing for a jumper or an IC is used to indicate the position of pin number 1. 2. A small number “1” or “2” marked near a corner of a jumper is used to indicate the position of pin number 1 or 2 for identification of all pins. -
Page 53: Jumpers And Connectors
JUMPERS AND CONNECTORS ON COMPONENT SIDE Position Part Spec Usage AUDIO1 F 3.5 M+S jack Mic. in / line out ports BAT1 Round socket CMOS battery socket Buzzer Reserved (System buzzer) HDR 1x7 w/H mini Inverter connector HDR 2x10 w/H mini LVDS connector for 15”... - Page 54 SMD fuse Fuse 5V/1.1A for USB0 SMD fuse Fuse 5V/1.1A for USB1 SMD fuse Fuse 5V/1.1A for USB4 SMD fuse Fuse 5V/1.1A for USB5 SMD fuse Fuse 5V/1.1A for USB6 SMD fuse Fuse 5V/1.1A for COM ports Poly fuse Reserved 12V/1.1A for COM ports Poly fuse Fuse...
-
Page 55: On Solder Side
ON SOLDER SIDE Position Part Spec Usage DDR2 SODIMM socket DDR2 SDRAM SODIMM HDR 1x3 CMOS data control HDR 1x2 VGA +12V DC supply select HDR 1x3 UPS status detect HDR 2x3 COM1/COM2 5V DC supply select HDR 2x3 Reserved COM1/2 ports DCD/12V HDR 2x3 COM3/COM4 5V DC supply select... -
Page 56: Lan Chip Control Enable/Disable
LAN CHIP CONTROL ENABLE/DISABLE STATUS OF JP4 LAN CHIP CONTROL « Short LAN function enabled Open LAN function disabled SOFTWARE AWARENESS OF UPS STATUS STATUS OF JP6 ON SOLDER SIDE UPS STATUS 1 – 2 short Normal (DCD signal) « 2 - 3 short Detect UPS status The UPS status is used to inform the software the power source the system is... -
Page 57: Usb Touch Setup
USB TOUCH SETUP STATUS OF JP11 ON SOLDER SIDE APPLICABLE OS « 1-2 short, 5-6 open Windows (Win98, Win2000, WinXP) 1-2 open, 5-6 open Linux or WinCE 1-2 short, 5-6 short MS-DOS « 3-4 short Touch panel type E or OEM 3-4 open Touch panel type F Please note for MS-DOS application of the USB touch, the “USB Mouse... -
Page 58: Cf Adaptor Card (Ks602A)
CF ADAPTOR CARD (KS602A) COMPONENT SIDE SOLDER SIDE IDE1 CONNECTORS ON COMPONENT SIDE Position Part Spec Usage CF card slot To accept CF memory card ON SOLDER SIDE Position Part Spec Usage IDE1 Connector 2x25 mini To connector IDE1 on main board KS-6615 / KS-6617 series Technical Manual 6 - 8... -
Page 59: Rs232 Touch Control Card
RS232 TOUCH CONTROL BOARD (KS604A) COMPONENT SIDE SOLDER SIDE CONNECTORS ON COMPONENT SIDE Position Part Spec Usage FPC connector To IR touch control panel ON SOLDER SIDE Position Part Spec Usage Connector 2x8 To RS232 IR touch connector CN15 on main board Connector 2x4 To JP12 on main board KS-6615 / KS-6617 series Technical Manual 6 - 9... -
Page 60: Sdvo Adaptor Card (Ks608A)
SDVO ADAPTOR CARD (KS608A) COMPONENT SIDE SOLDER SIDE CONNECTORS ON COMPONENT SIDE Position Part Spec Usage HDR 2x15 w/H mini To dual channel LVDS 17” LCD panel ON SOLDER SIDE Position Part Spec Usage mini Connector 2x15 To SDVO connector CN21 on main board Connector 2x3 mini To SDVO adaptor support CN22 on main board... -
Page 61: Service And Spare Parts
F/P sensor (Optical type) SC reader If the side mount unit is ordered together with the Jiva KS system, the SD side mount unit will be attached on the Jiva KS system when delivered. However, if the Jiva KS is delivered without such a unit and you want to install the... -
Page 62: Base Mount Upgrade Kit
BASE MOUNT UPGRADE KIT This upgrade is applicable to Jiva KS system with base stand in desktop application. On rear edge of the stand assembly, there is a rear connect cover as marked in the right picture. This area is designed for installing a 12”... -
Page 63: Base Installed Devices
this opening and have the interface cable passing the cable exit of the system base into the system I/O area. BASE INSTALLED DEVICES The devices installable to Gen 5 slim base include: a 2.5” system HDD and an UPS battery. The UPS battery should be installed per instructions in User’s Manual while the HDD must be accessed only by qualified technicians per below information. -
Page 64: 2.5" Hdd & Sdram In Main Unit
However, for reinstalling a new HDD into its bracket please refer to the left picture and note that the bracket itself is designed to accommodate both IDE and SATA interface 2.5” HDD therefore correct set of screw holes on the bracket must be checked to fix the SATA HDD into the bracket. -
Page 65: Separate Front Bezel Assembly
SEPARATE FRONT BEZEL ASSEMBLY Please refer to the picture above for a view of inside of front bezel assembly as detached from the main board of main unit. The touch panel is clipped to the LCD panel and then clipped to the plastic bezel. To access the inverter for the LCD panel please remove the circled screw and slide the inverter bracket down in the direction of the white arrow in the above pictures. -
Page 66: Cf Reader Slot Adaptor Card
17” LCD PANEL MODEL For models with a 17” LCD panel in the Jiva KS-66 series, there is a SDVO adaptor board on the system main board over connectors CN21, CN22 and CN23. The pictures of the top and bottom side of the SDVO adaptor board are at the right. -
Page 67: Ir Touch Panel Model
IR TOUCH PANEL MODEL For models with an IR (InfraRed) touch panel option, there is a RS232 touch control board on the system main board over connectors CN15 and JP12. The pictures of the top and bottom side of the RS232 touch control board are at the right. - Page 68 Please pay particular attention that the Aluminum die cast back cover plays vital role in system thermal balance and its interior contour is tailored to each component applied on the main board. Therefore, when replacing the main board only the exactly same version/grade/type should be used. Careless replacement of main board with deviation...
-
Page 69: Spare Parts List
SPARE PARTS LIST The column “Pos.” in the list below refers basically to the ID numbers indicated in the Assembly Drawing. If this column is not available, it refers to a packaging item. The column “S.” indicates the alternative selections available for that position. Please be noted that the information here is for reference only. - Page 70 Pos. S. Part Number Description 36564002000 KS-6615 M/B w/CPU Celeron M-1.0 GHZ & w/ IO (110) 2 Connector Plate 36566004000 Shoulder Screw Spring Set for KS-6615 w/CPU Celeron M-1.5 GHZ Only (2 Pcs Each) 36404004000 CF Card Upgrade Kit w/ Bracket & Adapter Board 10241300011 Push Latch, Black 16560301013...
- Page 71 Pos. S. Part Number Description 10558038082 Pan Head Screw #6/32-8L 16030302013 Front Cover for GEN 5 Slim Base, Black 46033602100 SATA HDD Adapter Board for GEN 5 Slim Base 36564003000 Cable Set for 2.5” SATA HDD 21955004000 2.5” SATA HDD 40G 36564004000 2.5”...
- Page 72 Pos. S. Part Number Description 21901302032 Li-Battery CR2032 10245109091 Cable Clip for LED Module Cable 21972080125 DC Power Adaptor 12V/80W for KS-6615 Series Slim Base (180cm) 21868100510 Power Cord for Australia for KS Series 21868200500 Power Cord for Europe for KS Series 21868300500...
- Page 73 CPEBAG64*70 PE Bag 64*70CM 16560900010 KS-6615/6617/7315/7317 User’s Manual KS-6615 / KS-6617 series Technical Manual 7 - 13...
- Page 74 ASSEMBLY DRAWING KS-6615 / KS-6617 series Technical Manual 7 - 14...
