Call processing is not available on one DS30 equivalent during the time
when it is out of service (OOS).
During the transfer procedure, move and take offline each DS30 equivalent.
In the PM table control, change the entry of the single DS30 equivalent. On
the new link, bring the equivalent back into service. The PM runs in
simplex mode until this procedure is complete.
Several commands display at the ENET level and card level. The
commands display to permit maintenance action for each DS30 equivalent,
or the whole fiber link.
At the ENET level of the MAP display, the output of the following
commands changes, but the input does not change.
FINDSTATE
SHOWBLOCK
The card level has an optional parameter for several commands. The
commands are for use with fiber links from the Quad DS512 Fiber Interface
Paddle Board (NT9X40). This parameter is at the card level of the MAP
display. This parameter associates with fiber links. This parameter does not
appear at the DS30 Interface Paddle Board (NT9X41) card level. This new
parameter is an additional number after the link number that is the DS30
equivalent. The fiber links possess the flexibility required to support InSv
transfer of fiber XPM. The affected commands are as follows:
ABTK
BSY
OFFL
QUERYEN
RTS
TRNSL
TRY
TST
Logs that relate to fiber links change to include DS30 equivalent
information. The word fiber appears in the log if the reported link is on a
fiber link. Maintenance action on a fiber link can be on the whole fiber, or a
set of DS30 equivalents within the fiber. When maintenance action is on a
set of DS30 equivalents, logs include a list of the affected equivalents. The
logs do not provide a list if the maintenance action affects all DS30
equivalents within the fiber.
