Appendix C: Shelf level status fields
Appendix C describes the meaning of different fields for the Shelf level of
the enhanced network (ENET).
Status overview version
Table 13-1 lists possible values for the slot status fields of the shelf level
display. Note that the slot status fields for each crosspoint card represents
the following two cards:
Table
Slot status field values
Field value
—
I
L
F
O
the crosspoint at the front of the slot
the paddle board for the link interface at the rear of the shelf
13-1xxx
Meaning
OK. The cards in the slot are in service (InSv).
Unequipped. The slot is not equipped.
In-service trouble (ISTb). The system detected a fault on
one of the cards in the slot. The affected card remains
InSv.
Link-service trouble. The system detected a fault on one of
the links on the paddle board in the slot. The affected link
remains InSv.
Fault. A fault is present on one of the links in the slot or the
paddle board.
Offline. The cards in the slot are offline (OFFL) as a result
of manual action.
—continued—
