Northern Telecom DMS-100 Series Maintenance Manual page 167

feature reports them to the network integrity analysis program for
correlation.
Interaction with network path test tool
This tool stores errored paths identified by network fabric tests in the path
fault buffer. The tool also stores errors identified by manual integrity check
traffic simulator tests in the path fault buffer.
Refer to table 8-4 for descriptions of network fabric commands.
Table 8-4xxx
Net fab commands
Tool Application
NETFAB Accesses the
netfab
directory.
Network integrity analysis package
The network integrity (net integ) analysis program identifies paths between
connected PMs where errors occur. The net integ program exchanges PCM
samples for calls in progress and CSM samples for signal integrity to
identify errors on speech links. Errors can occur in the hardware or
software. The program determines errors in the hardware by monitoring the
parity bits and integrity bytes. A network path with few mismatches of
Commands
STATUS. Displays the status
of the test and a summary of
results.
SUSPEND. Suspends
scheduled NETFAB tests.
RESUME. Resumes
scheduled NETFAB tests.
START. Manually implements
the NETFAB tests.
STOP. Stops a NETFAB test
manually implemented.
QUIT. Leaves the NETFAB
increment.
DMS-100 Family Networks Maintenance Guide BASE10
Problem isolation and correction 8-31
Reference
Refer to DMS-100 Family
Commands Reference Manual ,
297-1001-822
Refer to DMS-100 Family
Commands Reference Manual ,
297-1001-822
Refer to DMS-100 Family
Commands Reference
Manual ,297-1001-822
Refer to DMS-100 Family
Commands Reference Manual ,
297-1001-822
Refer to DMS-100 Family
Commands Reference Manual ,
297-1001-822
Refer to DMS-100 Family
Commands Reference Manual ,
297-1001-822
