6-28 Network related user interface commands
System level
The system level of the MAP display allows operating company personnel
to maintain the ENET for each node. A processing complex that consists of
the following components controls each ENET node. The components are
as follows:
Three versions of the system level are present. The commands available on
all three versions are identical. The type of information displayed is
different in each version. To access the system level correctly, obtain an
overview of all the ENET processing complexes. Also, obtain information
on the use of memory for a specified shelf. Another option is to obtain
information on the use of the central processing unit (CPU) for the shelf.
You can access the system level from the ENET, shelf, card, matrix levels of
the MAP display. You can access the system level from the system level.
To obtain the status overview of all the processing complexes in the ENET,
type
>SYSTEM
and press the Enter key.
To obtain detailed information on memory use for a specified shelf, type
>SYSTEM shelfno MEMORY
and press the Enter Key.
(for example, for shelf 1, enter >SYSTEM 1 MEMORY).
297-1001-591 Standard 04.03 March 1999
PATHTEST
BERT
NT9X13 card
NT9X26 card
NT9X36 card
NT9X40 card
Note: A node refers to a single plane, or shelf configuration of the
ENET. Plane 0 shelf 3 is an example of a node.
