Figure 6-24 shows an example of a MAP display for the path test level.
Figure 6-24xxx
Example of path test level
CM MS
. .
ENET
PATHTEST
0 Quit
2
Post
3
Define
4
5
Info
6 AltPath
7
AltTest
8
CpyBuf
9
CpyPath
10
DispBuf
11
12
13
Snapsht
14 Status
15
Start
16
Stop
17
Clear
18 Reset
TIME 14 : 40
The fields of the path test level indicate the number of defined path tests.
The fields also identify specified states. The total number of tests defined
equals the sum of the five status fields. Five possible test states correspond
to the five status fields of the path test level display. Refer to appendix E in
table 15-3 for descriptions of the five status fields.
Path test level menu commands
Command descriptions of the menu items occur in alphabetical order. Refer
to DMS-100 Family Commands Reference Manual, 297-1001-822, for a
complete description of command parameters.
ALTPATH command
Use the ALTPATH command to alter the path definition section of a test
record.
IOD Net
. . .
System
Plane 0 .
.
Plane 1
PATHTEST PENding SUSpended RUNning FINished ABorted
03
PATHTEST:
>
Network related user interface commands 6-53
