Crux Sightline RVCCH-75D Manual

INTERFACING SOLUTIONS
PRODUCT FEATURES:
Activates Uconnect Touchscreen Radio for enabling Video features
•
Aftermarket Rear-view Camera included
•
Automatically switches to Rear-view when car is in Reverse mode
•
Forced reverse camera view feature
•
• VIM function
Plug & Play Installation
•
PARTS INCLUDED:
RVCCH-75D Module
INSTALLATION DIAGRAM:
Connect RCAs and secure
RVC Video
Signal Input
OEM Radio
Harness
To Radio
R
Sightline
Multi View Integration
RVCCH-75D Harness
with tape all around
20 Ft. Coax Cable
BLACK
RED Wire
Wire
WHITE Wire
(Camera Power Output
GREEN Wire
+12V 250mA)
For Non Permanent
VIM function
BLACK
(Ground)
8-Pin Molex
ON
DP
DIP LED*
SWITCH
*LED RED = Power ON Status
LED BLUE = Data Bus ON Status
Rear View Integration Interface with VIM
Regulator
Line up Arrows
Push in Connectors
RED Wire
all the way
Tape O
(Not Used)
OR*
Chassis Ground
*Connect BLACK (ground) wire to chassis ground.
If video noise is present, we recommend connecting the
ground wire to the BLACK ground wire on the RVCCH-75D harness.
Represents Solder Joint
RVCCH-75D
for DODGE RAM Trucks
CDR-02 Camera
WHITE Wire
Parking Guideline
