INTERFACING SOLUTIONS
AUDI
2012 - 2014 A4
2012 - 2014 A5
2012 - 2014 A6
2012 - 2014 A7
2012 - 2014 A8
2012 - 2014 Q5
2012 - 2014 Q7
SAFETY PRECAUTIONS
1. Please read through the entire instruction manual before starting any of the installation procedures.
2. We recommend disconnecting the negative side of the battery until ready to code the vehicle.
3. Do not install any of the main modules near any major components or near the HVAC system,
as placing items near the HVAC may cause damage or overheating to the vehicle or interface.
4. We recommend not disconnecting any of the air bag connections behind the dash panels.
5. This product is under Crux's 1 year manufacturer's warranty. Warranty may be voided in the case where
the device shows proof of being opened or improper extreme force.
PARTS INCLUDED
AD-81M Main
Interface Module
TECH SERVICES
All our products are manufactured under strict quality control. Each device is tested before shipment. If you have any problems or if
you need technical support, contact us directly:
Crux Interfacing Solutions Tech Support
1 (855) 822-1348 (Mon - Fri - 9:00 AM - 5:00 PM)
R
e
. v
7 0
6 0
5 1
REAR-VIEW CAMERA INTEGRATION
FOR SELECT AUDI VEHICLES
with MMI 3G + 4G SYSTEMS
12-Pin Audio Input/Output
Cable
Time
CUL-03
Camera
6-Pin RGB Input Cable
1
RVCAD-81M
APPLICATION NOTES:
THIS INTERFACE REQUIRES THE
VEHICLES TO HAVE THE MMI
SYSTEM INSTALLED
WORKS FOR:
MMI Radios/ 4-Pin LVDS/ 3G + 4G
This interface does not o er the
Force RVC feature.
Contact Tech Support for more
information.
4-Pin Switcher Remote
www.cruxinterfacing.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Crux RVCAD-81M
Summary of Contents for Crux RVCAD-81M
- Page 1 4. We recommend not disconnecting any of the air bag connections behind the dash panels. 5. This product is under Crux’s 1 year manufacturer’s warranty. Warranty may be voided in the case where the device shows proof of being opened or improper extreme force.
- Page 2 RVCAD-81M REAR-VIEW CAMERA INTEGRATION FOR SELECT AUDI with MMI 3G + 4G VEHICLES 2012-2014 INTERFACING SOLUTIONS INSTALLATION OVERVIEW TO FACTORY DISPLAY 4-PIN LVDS DIP SET MENU AUDIO LVDS SIGHTLINE INTERFACE INTERFACING SOLUTIONS DIP SET AV 1 AV 2 CTRL POWER...
- Page 3 RVCAD-81M REAR-VIEW CAMERA INTEGRATION FOR SELECT AUDI with MMI 3G + 4G VEHICLES 2012-2014 INTERFACING SOLUTIONS CONNECTING THE INTERFACE Follow these steps to properly install the interface module. Step 1 - Remove the display to gain access to the factory LVDS connectors located behind the display.
- Page 4 RVCAD-81M REAR-VIEW CAMERA INTEGRATION FOR SELECT AUDI with MMI 3G + 4G VEHICLES 2012-2014 INTERFACING SOLUTIONS Connecting to the Audi GATEWAY Module The Audi Gateway Module looks like the picture below and can be found in di erent areas in the vehicle. Please see below for possible locations.
- Page 5 8-PIN (male plug) RVCAD-81M REAR-VIEW CAMERA INTEGRATION AUDIO IN/OUT FOR SELECT AUDI with MMI 3G + 4G VEHICLES 2012-2014 MULTIM INTERFACING SOLUTIONS CONNECTING THE LVDS These steps will help you with installing the LVDS connections on the module. Step 3 VIDEO - Connect the factory LVDS to the INPUT on our module, then connect our OUTPUT LVDS connection to the factory display.
- Page 6 RVCAD-81M REAR-VIEW CAMERA INTEGRATION FOR SELECT AUDI with MMI 3G + 4G VEHICLES 2012-2014 INTERFACING SOLUTIONS INPUTS AND OPTIONAL CONNECTIONS This will guide you on how to connect the AV and Camera inputs. Step 1 - Use the RCA inputs on the bottom of the module for your Camera and AV inputs.
- Page 7 RVCAD-81M REAR-VIEW CAMERA INTEGRATION FOR SELECT AUDI with MMI 3G + 4G VEHICLES 2012-2014 INTERFACING SOLUTIONS USING THE MENU BUTTONS The installer has MENU options available. These buttons are on the bottom side the main interface module. Step 1 - Use the 3 buttons on the bottom to adjust the following:...
- Page 8 RVCAD-81M REAR-VIEW CAMERA INTEGRATION FOR SELECT AUDI with MMI 3G + 4G VEHICLES 2012-2014 INTERFACING SOLUTIONS OPTIONAL ITEMS / SWITCHING SOURCES You can use the optional Toggle Switch to toggle the sources. Simply connect the 4-Pin connector to the side of the module.
