User Guide
EVALUATION BOARD HARDWARE
POWER SUPPLIES
Provide the following external power supplies:
12 V between 12 V DC and GND
►
−8 V between −8 V DC and GND
►
The GND input is provided on the EVAL-ADATE320EBZ. Each
device supply is decoupled to GND with a 10 μF and 0.1 μF
Table 1. Default Jumper Setup
Jumper No. Default
P3 Inserted
P4 Inserted
P5 Inserted
P6 Inserted
P7 Inserted
P1 Pin 2 to Pin 3
P2 Pin 1 to Pin 2
P11 Pin 1 to Pin 2
P8 Pin 1 to Pin 2
P9 Pin 1 to Pin 2
P10 Pin 1 to Pin 2
analog.com
Function
Current measurement terminal for VDD_TP (0.1 Ω sense resistor)
Current measurement terminal for VTTD_TP (0.1 Ω sense resistor)
Current measurement terminal for VCC_TP (0.1 Ω sense resistor)
Current measurement terminal for VEE_TP (0.1 Ω sense resistor)
Current measurement terminal for VTTC_P (0.1 Ω sense resistor)
BUS_RW control to indicate whether SPI bus is reading or writing
Device SPI chip select (CS_B_EVAL), on-board or external
Device SPI target device out (SDO_EVAL), on-board or external
Device SPI clock (SCLK_EVAL), on-board or external
Device SPI target device input (SDI_EVAL), on-board or external
Device reset signal (RESET_B_EVAL), on-board or external
EVAL-ADATE320
capacitor. Each device supply pin is again decoupled with a 0.1 μF
capacitor to GND. See the Figure 13
DEFAULT JUMPER SETUP
The default setup is for control by the PC through the USB port.
The default link options are listed in
and Figure 14 for reference.
Table 1.
Rev. 0 | 5 of 19
