User Guide
ORDERING INFORMATION
Quantity Reference Designator
5 R275, R276, R277, R278, R279
1 R29
2 R31, R32
1 R37
1 R5
1 R8
1 R9
5 U1, U8, VR1, VR6, VR8
1 U10
1 U11
1 U12
1 U14
3 U2, U3, U15
1 U17
1 U18
4 U4, U5, U6, U42
1 U7
1 U9
2 VR3, VR4
1 VR5
1 Y1
1 Not applicable
1 Not applicable
18 Not applicable
3 Not applicable
3 Not applicable
4 Not applicable
analog.com
Description
0.1 Ω resistors, SMD, 1%, 1 W, J-lead
12 Ω resistor, SMD, 1%, ¼ W, 1206
20 Ω resistors, SMD, 1%, 1 W, 2512,
AEC-Q200
330 kΩ resistor, SMD, 5%, 1/8 W, 0805,
AEC-Q200
5 kΩ through-hole resistor, trimmer, 10%,
¼ W, 6.8 mm × 5 mm × 7.8 mm
412 Ω resistor, SMD, 1%, 1/8 W, 0805,
AEC-Q200
12 kΩ resistor, SMD, 0.1%, 1/8 W, 0805,
AEC-Q200, high reliability
IC, 1 A, low dropout, complementary
metal–oxide semiconductor (CMOS)
linear regulator
IC, TTL dual, one shot
IC, CMOS, 2K, 16-bit microwire-
compatible serial electrically erasable
programmable read-only memory
(EEPROM)
IC, low voltage 1.15 V to 5.5 V,
4 channel, bidirectional, logic level
translator
IC, TTL, quad, two input, EX-OR
IC, TTL, quad, two input, positive AND
gates
®
IC, ultralow noise, LDO XFET 2.5 V
voltage reference with current sink and
source
IC, TTL, quad two line to 1 line
selectors/mux
IC,TTL, 8-bit, parallel out, serial shift
registers
IC,1-channel, high speed, USB to
multipurpose universal asynchronous
receiver-transmitter (UART)/first in, first
out (FIFO)
IC,TTL octal buffer/line driver with three-
state outputs
IC, linear, 3-term, adjustable regulators,
X1 M000386 and 1X M021972
IC, linear adjustable negative regulator,
add 1X M000386 AND 1X M021972
IC, crystal quartz
Fan, DC, 20 mm × 20 mm × 8 mm 5 V
DC vapo-bearing
Heat sink, forged with adhesive tap, 19
mm × 19 mm
Pins, connector center pin, 2.92 mm, 12"
diameter
Mounting kits for the TO-220 heat sink
Heat sinks, TO-202
Nuts, #2-56 X 60
EVAL-ADATE320
Part No. Manufacturing
RW1S0BAR100FE OHMITE
WCR1206-12RFI IRC Components of TT Electronics
CRCW251220R0FKEG VISHAY
ERJ-6GEYJ334V Panasonic
T63YA502KT20 VISHAY
ERJ-6ENF4120V Panasonic
ERA-6AEB123V Panasonic
ADP1708ARDZ-R7 Analog Devices
SN74LV123AD Texas Instruments
93LC56B-I/SN Microchip Technology
ADG3304BRUZ Analog Devices
SN74LV86AD Texas Instruments
SN74LV08AD Texas Instruments
ADR441BRZ Analog Devices
SN74LV157AD Texas Instruments
SN74LV164AD Texas Instruments
FT232HL-REEL FTDI
SN74ALVC244DW Texas Instruments
LM317AT/NOPB Texas Instruments
LM337T/NOPB Texas Instruments
ECS-120-20-4X ECS
MF20080V1-1000U-A99 SUNON Fans
APF19-19-10CB/A01 CTS Corporation
1090-07G Southwest Microwave Inc.
4880G Aavid
577404B00000G Aavid
KF2-256 PEM
Rev. 0 | 18 of 19
