Analog Devices EVAL-ADATE320EBZ User Manual page 17

User Guide
ORDERING INFORMATION
Quantity Reference Designator
5 LED_RESET, MANUAL_RESET,
SDI_SHOWN, SPI_RESET, USB_PWR
6 P1, P2, P8, P9, P10, P11
1 P81
4 PPMU_CMPH0, PPMU_CMPL0,
PPMU_M0, PPMU_S0
4 PPMU_CMPH1, PPMU_CMPL1,
PPMU_M1, PPMU_S1
7 R1, R3, R11, R16, R39, R41, R194
17 R10, R21, R23, R25, R26, R27, R28,
R34, R38, R44, R45, R46, R49, R50,
R59, R66, R153
33 R36, R43, R52, R53, R57, R77, R78,
R79, R80, R81, R82, R83, R84, R85,
R90, R91, R92, R93, R94, R95, R96,
R97, R98, R99, R100, R101, R103,
R104, R105, R158, R160, R255, R256
1 R12
1 R13
1 R14
1 R15
3 R18, R20, R150
2 R33, R151
4 R17, R227, R230, R232
2 R175, R176
3 R4, R6, R177
3 R30, R179, R180
1 R2
1 R217
1 R22
1 R221
1 R228
1 R231
3 R7, R24, R35
analog.com
Description
LED UNI-COLOR GREEN, 570NM
Connector PCB, Berg, headers, straight,
male, three position
Connector PCB, receptacle, side entry
shielded data link (SDL)
Connector PCB, white test points
Connector PCB, blue test points
10 kΩ resistors, SMD, 1%, 1/8 W, 0805,
AEC-Q200
3.01 kΩ resistors, SMD, 1%, 1/8 W,
0805, AEC-Q200
300 Ω resistors, SMD, 5%, 1/8 W, 0805,
AEC-Q200
200 Ω through-hole resistor, 5%, ½ W, 6
mm × 2.3 mm
39 kΩ resistor, SMD, 0.1%, 1/8 W, 0805,
AEC-Q200, high reliability
75 Ω resistor, SMD, 1%, 1/8 W, 0805,
AEC-Q200
64.9 kΩ resistor, SMD, 1%, 1/8 W, 0805,
AEC-Q200
249 Ω resistors, SMD, 1%, 1/8 W, 0805,
AEC-Q200
768 Ω resistors, SMD, 1%, 1/10 W, 0805,
AEC-Q200
20 kΩ resistors, SMD, 1%, 1/8 W, 0805,
AEC-Q200
10 Ω resistors, SMD, 1%, 2 W, 4527,
J-lead, AEC-Q200
3.3 Ω resistors, SMD, 5%, 1 W, 2512,
AEC-Q200
0 Ω resistors, SMD, 1/8 W, 0805, AEC-
Q200
2.05 kΩ resistor, SMD, 1%, 1/8 W, 0805,
AEC-Q200
715 Ω resistor, SMD, 1%, 1/8 W, 0805,
AEC-Q200
33 Ω through-hole resistor, 5% 5 W, 18
mm × 7.5 mm, AEC-Q200 CEMENT
33.2 Ω resistor, SMD, 1%, 1/8 W, 0805,
AEC-Q200
24.9 kΩ resistor, SMD, 1%, 1/8 W, 0805,
AEC-Q200
1.27 kΩ resistor, SMD, 1%, 1/8 W, 0805,
AEC-Q200
1.05 kΩ resistors, SMD,1%, 1/8 W, 0805,
AEC-Q200
EVAL-ADATE320
Part No. Manufacturing
CMD28-21VGC/TR8 Visual Communications Company
TSW-103-08-G-S Samtec
USB-B-S-F-B-TH-R Tyco Electronics Connectivity
TP-104-01-09 Components Corporation
TP104-01-06 Components Corporation
ERJ-6ENF1002V Panasonic
ERJ-6ENF3011V Panasonic
ERJ-6GEYJ301V Panasonic
CFM12JT200R Stackpole Electronics, Inc.
ERA-6AEB393V Panasonic
ERJ-6ENF75R0V Panasonic
ERJ-6ENF6492V Panasonic
ERJ-6ENF2490V Panasonic
ERJ-6ENF7680V Panasonic
ERJ-6ENF2002V Panasonic
WSC452710R00FEA VISHAY
ERJ-1TYJ3R3U Panasonic
ERJ-6GEY0R00V Panasonic
ERJ-6ENF2051V Panasonic
ERJ-6ENF7150V Panasonic
AC05AT0003309JAC00 VISHAY
ERJ-6ENF33R2V Panasonic
ERJ-6ENF2492V Panasonic
ERJ-6ENF1271V Panasonic
ERJ-6ENF1051V Panasonic
Rev. 0 | 17 of 19
