User Guide
ORDERING INFORMATION
BILL OF MATERIALS
Quantity Reference Designator
1 Not applicable
2 +12V, −8V
10 +2P5V_TP, +3P3V_TP, +5V_TP,
FAN_5V_TP, GND_3, VCC_TP, VDD_TP,
VEE_TP, VTTC_TP, VTTD_TP
29 A0, A1, A2, A3, A4, A5, A6, ALARM_B,
BUSY_B, C0, C1, D0, D1, D2, D3, D4,
D5, D6, D7, D8, D9, D10, D11, D12, D13,
D14, D15, RW, SDO_SHOWN
3 ALARMB_TP, BUSYB_TP, VTHERM
44 C2, C3, C4, C5, C9, C10, C12, C27,
C28, C29, C31, C33, C34, C37, C38,
C41, C44, C45, C46, C53, C61, C62,
C64, C66, C72, C74, C75, C80, C81,
C85, C137, C148, C149, C151, C156,
C163, C165, C233, C237, C253, C343,
C415, C420, C434
20 C6, C7, C11, C13, C18, C19, C20, C21,
C24, C26, C30, C35, C36, C39, C42,
C396, C401, C403, C404, C408
2 C14, C15
9 C69, C70, C96, C97, C145, C150, C157,
C164, C294
4 C8, C17, C22, C56
21 C25, C47, C49, C50, C52, C63, C65,
C67, C68, C71, C73, C76, C77, C87,
C204, C235, C238, C344, C347, C416,
C417
3 CLEAR_LEDS, DUT_RESET,
USB_RESET
18 CMPH0, CMPH0B, CMPH1, CMPH1B,
CMPL0, CMPL0B, CMPL1, CMPL1B,
DAT1, DAT1B, DATA0, DATA0B, DUT0,
DUT1, RCV0, RCV0B, RCV1, RCV1B
2 CR1, CR2
3 CR3, CR4, CR5
2 CR82, CR83
1 DUT
8 DUTGND, P3, P4, P5, P6, P7, P14,
VCCTHERM
4 E1, E2, E3, E4
2 GND_1,GND_2
4 GND_4,GND_5,GND_6,VREF_GND
1 JP1
analog.com
Description
Printed circuit board (PCB)
Connector PCB, banana jacks
uninsulated standard red
Connector PCB, red test points
Diodes, LED red, surface-mounted
device (SMD)
Connector PCB, yellow test points
0.1 µF ceramic capacitors, 50 V, 10%,
X7R, 0805, AEC-Q200
0.1 µF ceramic capacitors, 25 V, 10%,
X7R, 0603
27 pF ceramic capacitors, 50 V, 5%,
C0G, 0805
4.7 µF tantalum capacitors, 20 V, 10%,
3216-18
1000 pF ceramic capacitors,100 V, 10%,
X7R, 0805
4.7 µF ceramic capacitors, 25 V,
10%, X7R, 0805, low effective series
resistance (ESR)
Switches, push, SPST, normally open,
0.4 A, 20 V
Connector PCB, 2.92 mm jacks, 4-hole
flange, use with the 1× M014778
Zener diodes, suppressor electrostatic
discharge (ESD), 24 V DC, 0603
3.3 V Zener diodes, 1N5333B, 17-02
Rectifier diodes
IC, 1.25 GHz dual integrated DCL with
PPMU, level setting DACs, and on-chip
calibration registers
Connector PCB, Berg, jumpers, straight,
male, two position
Inductors, ferrite chip surface-mount
Connector PCB, banana jack,
uninsulated, standard black
Connector PCB, black test points
RES SMD 0 Ohm JUMPER 1/8W 0805
AEC-Q200
EVAL-ADATE320
Part No. Manufacturing
08_035315d Analog Devices supplied
108-0902-001 Cinch Connectivity Solutions
TP-104-01-02 Components Corporation
CMD28-21VRC/TR8 Visual Communications Company
TP-104-01-04 Components Corporation
08055C104K4T4A AVX Corporation
C0603C104K3RACTU KEMET Corporation
CC0805JRNPO9BN270 Yageo
TAJA475K020RNJ AVX Corporation
08051C102KAT2A AVX Corporation
C2012X7R1E475K125AB TDK
1825095-1 TE Connectivity, LTD
1012-01SF Southwest Microwave Inc.
PGB1010603MR Littelfuse Inc.
1N5333BG ON Semiconductor
1N5400G-T Diodes Inc.
ADATE320KCPZ Analog Devices, Inc.
69157-102HLF Amphenol FCI
BLM18EG601SN1D Murata Manufacturing
108-0903-001 Cinch Connectivity Solutions
TP-104-01-00 Components Corporation
ERJ-6GEY0R00V Panasonic
Rev. 0 | 16 of 19
