Icom IC-SAT100M Operating Manual page 8

3
OTHER FUNCTIONS
Using the Scan function
You can search the talkgroup that others are talking on.
The scan function operation differs, depending on the Scan Pause Timer setting (p. 10).
L Confirm "Scan Start/Stop" is assigned to [P2] key on the Menu screen. (p. 10)
Step 1. Preparation
Select a Scan Pause timer option on the Menu screen before using the Scan function.
Step 2. Using the Scan function
When the Scan Pause Timer is set to "Hold" (Default):
1. Push [Scan] to start scanning.
• " " blinks and "SCANNING" is displayed while scanning.
L Push [Scan] again to stop scanning.
• When the transceiver starts receiving, " ", "LISTENING" and the talkgroup name is displayed
2. After "OPEN" is displayed, push [PTT] to join the talk.
L The transceiver automatically resumes scanning when the talk is finished.
3. Push [Ignore] to exit the talk and resume scanning.
4. Push [Scan] to stop scanning.
00:00
IDLE
TRANSCEIVER 01
TALKGROUP01
Last Call
Scan
IDLE
SCANNING
TRANSCEIVER 01
Waiting Activity
Push
[Scan]
Last Call
Scanning
Start receiving
( Sounds the beep
Push
[Scan]
SCANNING
TRANSCEIVER 01
Waiting Activity
Last Call
Resume scanning
Start
00:00
receiving
( Sounds the
beep "Pi")
Scan
Push
"Pi")
[Ignore]
00:00
Push
[Ignore]
( Or the
talk is
Scan
finished)
5
00:00
LISTENING
TALKGROUP03
Last Call
Ignore
Receiving
Finished
receiving
00:00
OPEN
TALKGROUP03
Last Call
Ignore
Joining the talk
