OPERATING MANUAL
SATELLITE PTT
|SAT100M
INTRODUCTION
1 PANEL DESCRIPTIONS
2 BASIC OPERATION
3 OTHER FUNCTIONS
4 MENU SCREEN
5 CONNECTION AND INSTALLATION
6 SPECIFICATIONS AND OPTIONS
7 TROUBLESHOOTING

Advertisement

loading
Need help?

Need help?

Do you have a question about the IC-SAT100M and is the answer not in the manual?

Questions and answers

Related Manuals for Icom IC-SAT100M

Summary of Contents for Icom IC-SAT100M

  • Page 1 OPERATING MANUAL SATELLITE PTT INTRODUCTION |SAT100M 1 PANEL DESCRIPTIONS 2 BASIC OPERATION 3 OTHER FUNCTIONS 4 MENU SCREEN 5 CONNECTION AND INSTALLATION 6 SPECIFICATIONS AND OPTIONS 7 TROUBLESHOOTING...
  • Page 2 INTRODUCTION Thank you for choosing this Icom product. This product is designed and built with Icom’s state of the art technology and craftsmanship. With proper care, this product should provide you with years of trouble-free operation. Important READ ALL INSTRUCTIONS carefully before using the transceiver.
  • Page 3 ■ Using the Menu screen ......... 8 ■ Menu items ............ 8 Icom and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the United Kingdom, Germany, France, Spain, Russia, Australia, New Zealand and/or other countries.
  • Page 4 PANEL DESCRIPTIONS Microphone Description Microphone Speaker 1 EMERGENCY KEY [EMER] 8 BACK/HOME KEY [BACK] Hold down to transmit an Emergency call. z Push to return to the previous Menu screen. 2 SIDE 1 KEY [S1] z Hold down to exit the Menu screen. Push to display the Message List.
  • Page 5 PANEL DESCRIPTIONS Function display Icon area 00:00 Text area Last call Scan Key display area L The display is shown in English as an example. Select other languages on the Menu screen, if necessary. ([OK] > Display > Language) D Icon Area D Text Area Displays the status, preset transceiver name, and selected Talkgroup Name.
  • Page 6 BASIC OPERATION Receiving and transmitting D Turning ON the transceiver D Transmitting z Hold down [VOL] for 1 second to turn ON the CAUTION: DO NOT transmit without an antenna. transceiver. 1. Hold down [PTT]. • The transceiver searches a satellite. L “REQUESTING”...
  • Page 7 OTHER FUNCTIONS Using the Message function Using the Emergency mode The transceiver can receive and send short In the Emergency mode, the transceiver can transmit messages. an Emergency call, as shown below. NOTE: Using the Emergency mode requires the D Receiving Priority Talkgroup settings for the transceiver on the When receiving, a received message’s header and the command center.
  • Page 8 OTHER FUNCTIONS Using the Scan function You can search the talkgroup that others are talking on. The scan function operation differs, depending on the Scan Pause Timer setting (p. 10). L Confirm “Scan Start/Stop” is assigned to [P2] key on the Menu screen. (p. 10) Step 1.
  • Page 9 OTHER FUNCTIONS Using the Scan function When the Scan Pause Timer is set to other than “Hold”: 1. Push [Scan] to start scanning. • “ ” blinks and “SCANNING” is displayed and while scanning. L Push [Scan] again to stop scanning. •...
  • Page 10 OTHER FUNCTIONS Using the Surveillance function Using the RX Speaker function When this function is turned ON, the beep is not heard The transceiver can output received call audio to an and the backlight and the Status indicator do not light, external device through the D-Sub 25-pin even when a signal is received, or a key is pushed.
  • Page 11 MENU SCREEN Using the Menu screen You can use the Menu screen to set infrequently Menu changed values or function settings. Talkgroup The Menu screen is constructed in a tree structure. PTT Options You can go to the next tree level by pushing [RIGHT] Bluetooth or [OK], go back a level pushing [LEFT] or [BACK].
  • Page 12 Set the beep sound when pushing [PTT] on the NOTE: To pair an iOS device, update the optional VS-3 Bluetooth headset. IC-SAT100M main firmware to Revision 1.2. • OFF: No beep sounds when pushing PTT. Ask your dealer for details.
  • Page 13 MENU SCREEN Menu items D Functions Auto TX Mic Sel Select the microphone for transmitting an Emergency call. Auto Key Lock • Front Mic: Select the speaker microphone connected Turn the Auto Keypad Lock function ON or OFF. to the main unit. •...
  • Page 14 MENU SCREEN Menu items D Display D Information Backlight Battery Info Select a Backlight setting. Displays the battery voltage. • OFF: The backlight is always OFF. • ON: The backlight is always ON. RSSI • Auto (Key): When any switch except [PTT] is pushed, Displays the Received Signal Strength Indication the backlight lights for 5 seconds.
  • Page 15 CONNECTION AND INSTALLATION Installing the antenna R WARNING HIGH RF VOLTAGE! NEVER touch an antenna or antenna connector while transmitting. This could cause an electrical shock or burn. R WARNING HIGH RF VOLTAGE! NEVER install the antenna at any place that person easily touch the antenna while transmitting.
  • Page 16 CONNECTION AND INSTALLATION D About the Antenna unit IMPORTANT! • The Antenna unit must have an adequate ground connection. Otherwise, the antenna circuit may be damaged by a lightning strike or static electricity. Interference, RF feedback, and electrical shocks from other equipment could also occur.
  • Page 17 CONNECTION AND INSTALLATION D Antenna unit dimensions for building use On a wall: On a mast: unit: mm (inch) 85.4(3.4) 85.4(3.4) 85.4(3.1) 85.4(3.4) 76.8(3) 76.8(3) 76.8(3) 90(3.5) 76.8(3) 90(3.5) 44(1.7) 44(1.7) 17(0.7) 17(0.7) 17(0.7) 17(0.7) 44(1.7) 56(2.2) 56(2.2)
  • Page 18 CONNECTION AND INSTALLATION D Installation for vehicle use For vehicle use, the optional AH-40 is recommended to reduce obstacles around the antenna. ANTENNA When you operate a transceiver in a vehicle, you can replace the antenna element with an AH-40, and mount it on the roof instead of the Antenna unit.
  • Page 19 CONNECTION AND INSTALLATION D Installation example for vehicle use 3. Remove the antenna element. Antenna element (Keep in a safe place) 4. Remove the Polycarbonate cover on the top of the Antenna unit cover (1), and then make a hole in the Antenna unit cover (2).
  • Page 20 CONNECTION AND INSTALLATION D Installation example for vehicle use 5. Insert the coaxial cable through the Antenna unit cover, and then attach it to the RF unit. Coaxial cable AH-40 Antenna unit cover 6. Attach the Antenna unit cover. Y Type Screw...
  • Page 21 CONNECTION AND INSTALLATION D Installation example for vehicle use 7. Mount the Antenna unit to the Angle bracket. Flat Spring Bolt washer washer (M4×8) D Antenna unit dimensions for vehicle use unit: mm (inch) 202.4(8) 102(4) 19(0.7) 4-8 (0.5 ⁄ 16) (d) 68(2.7) D AH-40 Specifications •...
  • Page 22 CONNECTION AND INSTALLATION D Connecting the Antenna unit and the LAN cable • Connect the main unit and the supplied LAN cable (Length: approximately 20 m) as describe below. L The supplied LAN cable is a Shielded Ethernet Cable, so that use the supplied cable to connect the units. CAUTION: Be sure to ground the Antenna unit .
  • Page 23 This could damage the transceiver. L Low Voltage beep function The IC-SAT100M has the Low Voltage beep function to prevent battery over-discharge. When the battery voltage drops below 11 V or 10 V, L Information the Low Voltage beep 1 or 2 sounds every 3 seconds.
  • Page 24 Lever Mounting bracket IC-SAT100M To reduce vibration, place the cushion on the transceiver and put the sheet on it. L When mounting the bracket on the bottom side, attach the cushion and the sheet to the bottom of the transceiver.
  • Page 25 CONNECTION AND INSTALLATION Connecting the supplied microphone Connect the supplied microphone as illustrated below. D Attaching the microphone hanger Attach the microphone hanger as illustrated below. Microphone hanger Maintenance D Cleaning If the transceiver becomes dusty or dirty, wipe it clean with a soft, dry cloth. DO NOT use harsh solvents such as Benzine or alcohol when cleaning, as they damage the transceiver’s surfaces.
  • Page 26 SPECIFICATIONS AND OPTIONS Specifications L All stated specifications are subject to change without notice or obligation. D General • Frequency range: 1616 ~ 1626.5 MHz • Number of channels: 240 Channels • Type of emission: 41K7Q7W • Duplexing method: TDD (Time Domain Duplex) •...
  • Page 27 The Bluetooth headset with a [PTT] switch. About the third party Bluetooth headsets: Icom has checked the PTT operation with some 3M Peltor headsets such as the WS Headset XP, WS ProTac XP and WS Alert XP. (Compatibility not guaranteed.) NOTE: Bluetooth headsets are usable only on the transceiver version that have a built-in Bluetooth.
  • Page 28 SPECIFICATIONS AND OPTIONS Using a Bluetooth headset ® (For only the transceiver with the Bluetooth function.) The transceiver can operate with Bluetooth headsets. 2. Entering the VS-3 Pairing mode The communication range of Bluetooth is 1. Confirm the VS-3 is turned OFF. approximately 10 meters (33 ft).
  • Page 29 TROUBLESHOOTING Troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION REF. The transceiver does • Bad connection to the power supply. • Confirm the connection to the p. 20 not turn ON. transceiver and power supply. • Fuse is blown. • Find the cause, repair, and then p.
