Icom IC-SAT100M Operating Manual page 13

4
MENU SCREEN
Menu items
D Functions
Auto Key Lock
Turn the Auto Keypad Lock function ON or OFF.
• OFF: Turns OFF the function.
• ON: The transceiver locks the keypad* when
no key is pushed for 30 seconds.
* Except for [EMER], [PTT], [VOL], and
Talkgroup selector.
Key Setup
Assign functions to the [P1] and [P2] keys.
Key Setup
P1 Key
P2 Key
✔
✔
✔
Assignable functions
[P1]
OFF (No function is assigned) OFF (No function is assigned)
Talkgroup List (p. 8)
My Position (p. 11)
Surveillance (p. 7)
AquaQuake (p. 7)
Last Call Play (p. 7)
Message List (p. 8)
PC Command
Select a connecting method to connect the transceiver
to a PC.
• OFF: Nothing is selected.
• D-Sub 25: Select when connect to a PC using a
connection cable with D-Sub 25 pin.
• Bluetooth*: Select when connect to a PC using a
Bluetooth device.
• TCP: Select when connect a VE-PG4 using a
LAN cable
* For only the transceiver with the Bluetooth function.
Scan Pause Timer
Select a Scan Pause timer option.
• Hold: When a talk is detected, the scan pauses on
the talkgroup until the detected talk ends.
• 5 Sec ~ 15 Sec: When a talk is detected, the scan pauses
on the talkgroup for the selected period
of time. After the period ends, the scan
continues even though the talk has not
finished.
L To stay on the talkgroup, push [Stay].
See page 6 for details.
[P2]
Scan Start/Stop (p. 5)
Lock (p. 4)
Auto TX Mic Sel
Select the microphone for transmitting an Emergency
call.
• Front Mic: Select the speaker microphone connected
to the main unit.
• External Port: Select the external input connected to the
D-sub 25 pin.
• BT Mic*: Select the microphone connected using
Bluetooth.
* For only the transceiver with the Bluetooth function.
ExtPTT Mic Sel
Select which microphone to use when pushing an
External PTT connected to the D-Sub 25 pin cable.
• Front Mic: Select the speaker microphone connected
to the main unit.
• External Port: Select the external input connected to the
D-sub 25 pin.
• BT Mic*: Select the microphone connected using
Bluetooth.
* For only the transceiver with the Bluetooth function.
D Clock
Clock Display
Select whether or not to display the clock on the Main
screen.
Time Format
Select time format for the clock.
✔
✔
✔
✔
✔
Clock Time Zone
Select your local time zone.
✔
✔
✔
✔
✔
DST
Selects whether or not to use Daylight Saving Time
(DST) for the clock.
10
Time Format
12 hours
24 hours
Clock Time Zone
UTC-02:00
UTC-01:30
UTC-01:00
UTC-00:30
UTC+00:00
