2
BASIC OPERATION
Receiving and transmitting
D Turning ON the transceiver
z Hold down [VOL] for 1 second to turn ON the
transceiver.
• The transceiver searches a satellite.
• When the transceiver connected and registered to
the satellite, the status "IDLE," transceiver name, and
Talkgroup name is displayed.
L Push [Last Call] to playback the received call.
L Push [UP] or [DOWN] to display the Talkgroup List.
L Rotate Talkgroup selector to select a talkgroup.
Hold down
D Receiving
When receiving, "LISTENING," and the source
transceiver's name are displayed, and audio should
be heard.
L Rotate [VOL] to adjust the audio output level.
LISTENING
TRANSCEIVER2
TALKGROUP01
Last Call Ignore
NOTE: The transceiver receives and transmits using
several satellites orbiting the same orbit. Receiving
and transmitting may fail, depending on the satellite
position or any obstacles between the transceiver and
satellites.
D Transmitting
CAUTION: DO NOT transmit without an antenna.
1. Hold down [PTT].
L "REQUESTING" is displayed while the transceiver
requests the transmission.
2. When "TALKING" is displayed, speak at your
normal voice level.
L You can continuously transmit up to the period of
time allowed by the system.
TALKING
TRANSCEIVER1
TALKGROUP01
Last Call Scan
NOTE:
• If the connection becomes poor while transmitting,
the transceiver sounds the beep "PuPu" in 1.5 second
intervals.
• You cannot transmit while listening to the received audio.
Before transmitting, confi rm the receiving is fi nished by
the beep "Pi" and the display "OPEN."
D Scan and Ignore
L Assign the function to the [P2] key in the Menu
screen to use Scan function.
[OK] > Functions > Key Setup > P2 Key
[Scan]
Push [P2] to start scanning. (pp. 5 ~ 6)
• " " blinks while scanning.
• " " is displayed when a scan is paused.
L When a Scan is paused by detecting a signal, [P2]
changes from Scan to Ignore.
[Ignore]
Push [P2] to ignore the received call. (pp. 5 ~ 6)
L The Ignore function will be canceled if there are no more
calls for 90 seconds or longer.
• The scan starts again except in the selected Talkgroup.
L Push [P2] to exit the Scan function.
3
