Compaq 3000R - ProLiant - 128 MB RAM Notice page 55

agents monitor the device for specific parameters such as unused disk space, memory
configuration, resource utilization, temperature, fan operation, and so forth.
Additionally, through interrogation of the agents, management software like
TopTools Device Manager provides OS version information, remote diagnostic
capabilities, BIOS flashing capabilities, distribution of HP drivers, etc.
· Instant TopTools: With HP Instant TopTools and a browser, you can get the latest
information about an HP Netserver. Run from a client or at the server's console,
Instant TopTools allows you to view alerts for that server, its status, and the status of
the devices in the server (such as memory, mass storage, system environment, power
and BIOS versions. Instant TopTools does not require the HP Netserver Agent
software to function. However, installing the agent software allows Instant TopTools
to obtain more events that describe the state of your server's installed hardware
components.
System Preparations
The first step to installing TopTools is to identify which TopTools product would be right
for your server needs. If you install TopTool agents you will need TopTools Device
Manager, Instant TopTools or an equivalent management program to retrieve and
interpret information from the agents. Loading Instant TopTools on a system with agents
will increase its management capabilities. Once you decide to install one or both
TopTool products, then check to make sure your system is prepared for the TopTools
installation. This document will guide you through the installation of SNMP services,
TopTool Agents and Instant TopTools.
NOTE: If using DHCP the following page will shows "Obtain an IP address
automatically" selected and the rest of the page is grayed out.
1. First verify that your TCP/IP networking and browser is properly installed,
configured and fully operational. You can review your settings on the Internet
Protocol (TCP/IP) properties screen.
2. If you need to add SNMP go to the "AddRemove Program" application and add
"Management and Monitoring Tools".
3. To add SNMP services and configure them, go to the Components Services screen
under Administrative tools | Component Services | Services (Local) | SNMP
Service.
4. Right click "SNMP Service" and select properties.
5. Selecting properties will display the SNMP Service Properties window. The tabs that
you'll need to configure are the Agent, Traps and Security tabs, as follows:
Agent tab. All you need to fill out is the your name and location. The items checked
off in the Service area are the default values. Use the " ? " help system to find out
additional information on all items.
