Samcon RoughCam IPQ1656 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IPQ1656
®
RoughCam
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RoughCam IPQ1656 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samcon RoughCam IPQ1656

Summary of Contents for Samcon RoughCam IPQ1656

  • Page 1 IPQ1656 ® RoughCam User Manual...

  • Page 2: Table Of Contents

    Table of contents Introduction ......................5 Technical data ......................5 Illustration of the model key ................. 5 Electrical parameters of the camera ..............7 Connection cable....................7 2.3.1 Connection cable for models without heater (SKD01-T/ASKD02-T) ......... 7 2.3.2 Connection cable for models with heater (SKDP03-T/ASKDP03-T) ......... 8 2.3.3 Connection cable for model with cool.Jacket (SKD05-HT) ............
  • Page 3 Fig. 6-1 Removing the weather protection roof (1/2) (similar illustration) ......23 Fig. 6-2 Removing the weather protection roof (2/2) (similar illustration) ......23 Fig. 6-3 Opening the RoughCam IPQ1656 (similar illustration) ........24 Fig. 6-4 Mounting adapter with built-in components ............25 Fig.
  • Page 4 07.05.2024 S. Heinz Compilation of the document, from Alexander Kruse Digital unterschrieben von Alexander Kruse the document of the user manual DN: cn=Alexander Kruse, o, ou, email=a.kruse@samcon.eu, c=DE Datum: 2025.03.06 12:05:46 +01'00' ExCam IPQ1656 Doc.-ID: 240430-PT10BA-HS-RoughCam-IPQ1656_en_rev.00.docx, Page 4 of 32...

  • Page 5: Introduction

    Introduction The RoughCam IPQ1656 is a powerful mega-pixel IP camera of the latest generation, with 4-megapixel resolution at 2688 x 1512 pixels. The camera has a high-definition tele- vision resolution. It is equipped with a powerful remote zoom and focus lens (with i-CS).
  • Page 6 LL.H= PTC heater installed (T > -60°C) N.HH= Optional housing cooling cool.Jacket (T < +130°C) 005.N = Length of the connection line in meter at delivery; 5m is the standard cable length, max. cable length is: 005…100 [m] 005.N = Non armoured cable 005.A = Armoured cable...

  • Page 7: Electrical Parameters Of The Camera

    Electrical parameters of the camera Supply of 24 V DC for the heating: Voltage supply: 24 V DC Power consumption: approx. 40W@-60°C (temperature-dependent) Power supply of the camera over Ethernet (PoE): Voltage supply: PoE, IEEE 802.3af/802.3at type 1 class 3 Reference voltage: +48 V DC (44...54 V DC) Maximum power consumption:...

  • Page 8: Connection Cable For Models With Heater (Skdp03-T/Askdp03-T)

    4 x 2 x AWG23/1 CAT.6 Properties: PUR halogen-free, flame-retardant, UV-re- sistant, chemical resistance, shielded (see www.samcon.eu Quicklink: https://www.samcon.eu/fileadmin/documents/en/60- Assembling and mounting/ASKD02-T_Datasheet.pdf Fig. 2-2 Sectional view of ASKD02-T 2.3.2 Connection cable for models with heater (SKDP03-T/ASKDP03-T) Systemcable SKDP03-T: Outside diameter: 12.40 ± 0.3 mm...

  • Page 9: Connection Cable For Model With Cool.jacket (Skd05-Ht)

    4 x 2 x AWG23/1 CAT.6 Performance elements: 3G1.5 (BK-BU-GN/YE) Properties: PUR halogen-free, flame-retardant, UV-re- sistant, chemical resistance, shielded Quicklink: https://www.samcon.eu/fileadmin/documents/en/60- Assembling%26mounting/ASKDP03-T_Datasheet.pdf Fig. 2-4 Sectional view of ASKDP03-T 2.3.3 Connection cable for model with cool.Jacket (SKD05-HT) Systemcable SKD05-HT: Outside diameter: 6.60 ± 0.2 mm...

  • Page 10: Video-Technical Characteristics

    User Manual! Attention! Only original parts of SAMCON Prozessleittechnik GmbH may be used for repairs. Repairs concerning the explosion protection may only be carried out in accordance with the nationally applied regulations and by SAMCON Prozessleittechnik GmbH.

  • Page 11: Installation

    Installation For erecting and operating the camera, the relevant national regulations, as well as the generally accepted rules of technology shall prevail. Before mounting the camera, thor- oughly check it for any transport damage, especially on the housing and cable. Installation, electrical connection and the first start must only be carried out by qualified specialists.
  • Page 12 Drawings for drill hole patterns and further information can be viewed on our product page: Quick link: https://www.samcon.eu/en/products/roughcam/roughcam-ipq1656/ Option mounting accessories Wall bracket WALL MOUNT BRACKET WMB-VA2.3 Wall bracket for devices of T10-VA2.3 series WMB-... Suitable for hanging the camera on walls.

  • Page 13: Electrical Connection

    (right) (see Figure 5.1). The cross-section of the equipotential bonding should comply with the National Ground Rules (at least 4 mm Fig. 5-1 RoughCam IPQ1656 Equipotential Bonding Doc.-ID: 240430-PT10BA-HS-RoughCam-IPQ1656_en_rev.00.docx, Page 13 of 32...

  • Page 14: Connection And Fusing

    IEEE 802.3af and 802.3at type 1 Class 3 ("classification current: 26-30 mA @48VDC, max. feed-in power (power source equipment): 15.4 W, maximum offtake (power device): 6.49 - 12.95 W"). The data transfer of the RoughCam IPQ1656 series is done via a 100 Mbit/s Ethernet connection (100BASE-TX).
  • Page 15 Fig. 5-3 RoughCam IPQ1656 T10-VA2.3.K3.BOR2-N.H-xxx.N-T Fig. 5-4 RoughCam IPQ1656 T10-VA2.3.K3.BOR2-N.H-005.N-P Fig. 5-5 RoughCam IPQ1656 T10-VA2.3.K3.BOR2-LL.H-005.N-P Doc.-ID: 240430-PT10BA-HS-RoughCam-IPQ1656_en_rev.00.docx, Page 15 of 32...

  • Page 16: Video Tutorial

    Figure 5.6 shows RoughCam IPQ1656 with active cooling cool.Jacket. Fig. 5-6 RoughCam IPQ1656 T10-VA2.3.K3.BOR2-N.HH-010.N-T Video Tutorial: Please view our video tutorial : “SAMCON 01 Wiring the cable SKDP03-T to the junction box” https://go.samcon.eu/v01 Fig. 5-7 Video Tutorial ExTB-3 The pin assignment of the SKD01-T is executed in accordance with the standard EIA/TIA-...
  • Page 17 The pin assignment of the ASKD02-T is executed in accordance with the standard EIA/TIA- 568B for 100BaseTX and 24VDC, as follows: Camera Colour Terminal Cross-sec- Comment ASKD02-T tional sur- (T568B) (IEC60757) face Reinforcement YE / GN 2.5 mm Flex WH / OG 0.26 mm Solid conductor 0.26 mm...
  • Page 18 L+ 24VDC 1.5 mm L- 24VDC YE / GN 1.5 mm Tab. 5-5 Wire assignment of terminal box (model LL/ASKDP03-T) SKD01-T SKD01-T RoughCam IPQ1656 housing Fig. 5-8 Sample circuit of terminal box (without heater) Doc.-ID: 240430-PT10BA-HS-RoughCam-IPQ1656_en_rev.00.docx, Page 18 of 32...
  • Page 19 RoughCam IPQ1656 housing Fig. 5-9 Sample circuit of terminal box (heater integrated) Fig. 5-10 Photo of the wired terminal box Doc.-ID: 240430-PT10BA-HS-RoughCam-IPQ1656_en_rev.00.docx, Page 19 of 32...

  • Page 20: Fusing

    Finally, check your network installation with a Class-D Link Test. Note: If the camera is equipped with a camera cooling system (SAMCON cool.Jacket for model key type N.HH), the wiring is executed via the cable SKD05-HT. The pin assignment of the SKD05-HT is executed in accordance with the standard EIA/TIA-...

  • Page 21: Plug Assignments (Rj45)

    Tab. 5-7 Recommendation for fusing 5.2.2 Plug assignments (RJ45) The data transfer of the RoughCam IPQ1656 uses a 100 Mbit/s Ethernet connection (100BASE-TX). If the cable termination uses a plug, the latter should be plugged into the RJ45 PoE slot of the network device (PSE).

  • Page 22: Tests Prior To Switching On The Voltage

    Fig. 5-11 Plug assignment, RJ45 5.2.3 Tests prior to switching on the voltage Attention! Prior to starting the device, perform all tests as indicated by the national regulations. Furthermore, check the correct function and installation of the device in accordance with this User Manual and other applicable regulations.

  • Page 23: Work Preparation

    • Prevent static charge at all costs Opening the pressure-resistant housing If the RoughCam IPQ1656 is equipped with a weather protection roof (optional acces- sory), remove the roof before you start working! To do so, untighten the 4x12mm lens screws M4*0.7 at the front and rear sides of the bracket holders (Fig. 6-1).
  • Page 24 (H8f7 - DIN ISO 286) of the camera body and flange may not be tilted! Risk of damage to the flame-proof gap (DIN EN 60079-1:2012)! Fig. 6-3 Opening the RoughCam IPQ1656 (similar illustration) Attention: The mounting adapter with the housing’s PTC heater, camera module and op- tics, as well as the temperature control and (if applicable) auxiliary relays and terminal box are fixed on the cable and supply flange.

  • Page 25: Removing/Inserting A Sd Memory Card

    Removing/inserting a SD memory card Note: The RoughCam IPQ1656 disposes of a micro SDHC memory card slot (see Fig. 6-4 1). Saved video files can be played and deleted via the web interface. They are also available in a download list. Moreover, the videos available on the memory card can also be ac- cessed via an FTP server in the network.

  • Page 26: Status Led

    The user can see the Status LED only if the camera housing is open. Hardware Reset To re-set all parameters of the RoughCam IPQ1656 (including the IP address) to default setting, a hardware reset has to be carried out. The parameters can be either reset via the web interface or manually. If the camera in the network can no longer be reached or its state is uncontrollable, the reset should be per- formed manually.

  • Page 27: Battery

    Battery RoughCam IPQ1656 is equipped with a high-temperature resistant Panasonic button cell BR2330A/VAN. This cell supplies energy to the internal real time clock (RTC). The cus- tomer is not allowed to replace the battery! In this case, please contact the manufacturer.

  • Page 28: Network Access And Visualization

    Assigning the IP address The RoughCam IPQ1656 is intended for use in an Ethernet network and requires an IP address to access and control it. In most of today’s networks, a DHCP server is integrated. This server automatically assigns an IP address.

  • Page 29: Password/ Identification

    It can also be used to manually assign a static IP address. For this purpose, the RoughCam IPQ1656 network camera should be installed in the same physi- cal network segment (physical subnet) as the computer on which the AXIS IP Utility is running.

  • Page 30: Maintenance/ Modification/Repairs

    SAMCON Prozessleittechnik GmbH or by an electrical technician authorized by SAMCON Prozessleittechnik GmbH. Rebuilding of or alterations to the devices are not permitted. If in doubt, send the part in question back to SAMCON Prozessleittechnik GmbH. Disposal/ Recycling When disposing of the device, nationally applicable regulations must be observed.

  • Page 31: Further Documentation

    If you wish additional technical information, please contact us at: support@samcon.eu Further documentation Further documentation isvailable in the download area of the product website: https://www.samcon.eu/en/products/roughcam/roughcam-ipq1656/ Doc.-ID: 240430-PT10BA-HS-RoughCam-IPQ1656_en_rev.00.docx, Page 31 of 32...
  • Page 32 Schillerstrasse 17, 35102 Lohra-Altenvers, Germany www.samcon.eu, info@samcon.eu Phone: +49 6426 9231-0, fax: - 31...
