Summary of Contents for Samcon ExCam IPM1137
- Page 1 ® ExCam IPM1137 User Manual...
-
Page 2: Table Of Contents
Table of contents Introduction ............................4 Technical data ............................4 Explosion protection ........................4 Illustration of the model key ......................5 Electrical parameters of the camera ....................6 Cables and glands ......................... 6 2.4.1 Connection cable for devices with flipConnect ................6 Connection cable Ex-d –... - Page 3 Figure 6-1 Removing the weather protection roof ............18 Figure 6-2 Wiper in center position .................. 19 Figure 6-3 Opening the ExCam IPM1137 (similar illustration) ......... 19 Figure 7-1 Axis IP Utility ....................24 Figure 7-2 User interface to operate the wiper ..............24 Figure 7-3 Turning the wiper on ..................
-
Page 4: Introduction
Introduction The ExCam IPM1137 is a cost-effective megapixel network camera for use in hazardous areas. The camera offers 5 MP resolution (2592 x 1944),a powerful remote zoom focus lens and a Machine Learning Processing Unit (MLPU). It is approved according to Directive 2014/34/EU (ATEX), IECEx, INMETRO and EAC-Ex and more. -
Page 5: Illustration Of The Model Key
Explanations: ExCam IPM1137 Functional camera description of the ExCam Series (technical data/ specification of the individual camera module) T08 = SAMCON Production- Type 08 VA2.2.K1.BOR = T07 ex d housing (stainless steel 1.4404) with large diameter Ø =113mm) VA2.2.K4.BOR = T07 VA2.2 housing with medium body length (L... -
Page 6: Electrical Parameters Of The Camera
10 x D after relocation Data line: 4 x 2 x AWG23/1 CAT.6 Properties: PUR halogen-free, flame-retardant, UV-re- sistant, chemical resistance, shielded (see www.samcon.eu Quicklink: https://www.samcon.eu/fileadmin/documents/en/60- Assembling%26mounting/ASKD02-T_Datasheet.pdf Figure 2-1 Sectional view of ASKD02-T Doc.-ID: 241029-PT08BA-SHe-ExCam IPM1137_en_rev.00.docx, Page 6 of 28... -
Page 7: Cable Glands Poe And Protection Hose
2.4.3 Cable glands PoE and protection hose System cable ASKD02-T gland Capri ADE4F Cap No.6 Documentation ADE4F, Declaration of Conformity, Instruction Manual, Datasheet Video-technical characteristics We use the AXIS M1137 MkII Box Camera in a pressure-resistant enclosure. For details, ®... -
Page 8: Safety Instructions
Please absolutely observe the installation instruction’s safety direc- tions of the T08 ExCam series! Quick link: https://www.samcon.eu/fileadmin/documents/en/22-Ex-Network-Cameras/ExCam-Series-T08-EX-Installation-Manual-2020.pdf It is absolutely mandatory to adhere to the national safety regulations and regula- tions for prevention of accidents, as well as to the safety instructions given below... -
Page 9: Installation
The pre-installed RJ45 plug may only be connected in a safe area (non-Ex zone)! Prior to the first use, you should test the camera corresponding to the instructions given in the chapter Commissioning. Please observe the national safety regulations and regulations for prevention of ac- cidents, as well as to the safety instructions given below in this User Manual! Installation For commissioning and operating the camera, the relevant national regulations, as well as... - Page 10 Please pay attention to the national and local regulations for mounting heavy loads. In case of doubt, take appropriate security measures. Drawings for drill hole patterns and further information can be viewed on our product page: Quick link: https://www.samcon.eu/en/products/network/excam-ipm1137/ Optional mounting accessories WALL MOUNT BRACKET WMB-VA2.1/2.2 Wall bracket Wall bracket for devices of T08-VA2.2 series...
-
Page 11: Electrical Connection
The user is NOT authorised to do electrical connection procedures inside the pressure-resistant enclosure. Potential equalization Figure 5-1 ExCam IPM1137 potential equalization Potential equalization/grounding of the camera housing is absolutely necessary, in order to avoid static charges and thus the formation of sparks. For this purpose, a screw terminal... -
Page 12: Connection Work At The Device And Fuses
We show the procedures of electrical connection via flipConnect in the following video tutorial: “Plug & Play Cable Connection via flipConnect” https://go.samcon.eu/flipconnect Figure 5-2 Connection via flipConnect Unscrew the red blind plug (with integrated auxiliary tool) from the housing and keep it save. - Page 13 Choose a suitable cable and cable gland (e.g. the provided). Put the gland over the ca- ble. Caution: the selected plug must be of the same length or shorter than the supplied one. Follow the respective instructions of the components. Plug in the RJ45 plug with the cable pigtail into the socket until the lock engages.
- Page 14 Push the cable down. Fasten the cable gland’s outer ring. Use Loctite and refer to the operating instructions of the selected gland in order to observe the appropriate fastening torques. Done. Attention! Use appropriate RJ45 plug! Pay attention to shielding, cross-section and outer diameter of the cable! Doc.-ID: 241029-PT08BA-SHe-ExCam IPM1137_en_rev.00.docx, Page 14 of 28...
-
Page 15: 5.2.1.1 Appropriate Cables & Cable Entries
(nylon PA3200, red) for fitting a suitable explosion- proof cable kit. Quicklink for suitable cables and cable glands: https://www.samcon.eu/fileadmin/documents/de/60-Montage%26Installation/flipConnect-Compatibility.pdf An essential component of system safety is the correct selection of cables, wires and ca- ble entries. -
Page 16: Plug Assignments (Rj45)
5.2.1.2 Plug assignments (RJ45) The data transfer of the ExCam IPM1137 uses a 100 Mbit/s Ethernet connection (100BASE-TX). If the cable termination uses a plug, the latter should be plugged into the RJ45 PoE slot of the network device (PSE). Prior to connecting it to the camera, the network device (PSE) can already be supplied with power, hence there is no „power ON“... -
Page 17: Tests Prior To Switching On Voltage
5.2.2 Tests prior to switching on voltage Attention! Prior to starting the device, perform all tests as indicated by the national regulations. Furthermore, check the correct function and installation of the device in accordance with this User Manual and other applicable regulations. -
Page 18: Working Inside The Housings (Ex-D)
6.1.1 Opening the camera housing If the ExCam IPM1137 is equipped with a weather protection roof this has to be removed prior to starting your work! To do so, loosen the 4x12mm button head screws M4*0.7 at the front and rear sides of the bracket holders (Figure 6-1). - Page 19 Figure 6-2 Wiper in center position To open the stainless-steel housing (T07 VA2.X.x.x) of ExCam IPM1137, loosen the eight cylinder-head hexagon screws (DIN 912/ ISO 4762) together with their spring rings (DIN 127A) on the rear side of the cable and power supply flange (see Figure 6-2). Caution: do not touch the screw threads with your skin or clothes! On the threads, there is LOCTITE®...
-
Page 20: Removing / Inserting A Sd Memory Card
Removing / inserting a SD memory card Note: The ExCam IPM1137 has a slot for a micro SDHC memory card (card not included). Saved video files can be played and deleted via the web interface. They are also available in a download list. - Page 21 5. IP address and password can be redefined. If the hardware reset is not satisfactory or the network camera shows serious conflicts or does not work as usual (errors in the browser visualisation, frozen images, control commands no longer processed, slowing down of the system, etc.), it may be necessary to re-install the current firm- ware, or to install an update (see Chapter 7).
-
Page 22: Closing Of The Pressure-Resistant Housing
Closing of the pressure-resistant housing For closing the housing, proceed in reverse order as when opening. Use exclusively origi- nal screws included in the supply. The cable and power-supply flange is fixed by 8 cylinder-head screws M4*0.7 (ISO metric right-turning) with 12 mm thread length (DIN 912/ ISO 4762, grade 6g). Materials of bolted connections are identical to the pressure-resistant stainless steel housing (standard mate- rial no. -
Page 23: Network Access And Visualization
Assigning the IP address The ExCam IPM1137 is intended for use in an Ethernet network and requires an IP address to access and control it. In the most today’s networks, a DHCP server is integrated. This server automatically assigns an IP address. -
Page 24: Password/ Identification
How to start the wiper The ExCam IPM1137 is equipped with a wiper. The wiper can be started via a button in the lower right corner of the web interface (see Figure 7-2). Figure 7-2 User interface to operate the wiper The factory settings of the wiper are pre-set to wipe 3 times in a row. - Page 25 The start button for the wiper can be activated or deactivated. Figure 7-3 Turning the wiper on Intermittent wiper controls can be configured via CGI command by the video management system. If you have any questions, please write to support@samcon.eu. Doc.-ID: 241029-PT08BA-SHe-ExCam IPM1137_en_rev.00.docx, Page 25 of 28...
-
Page 26: Maintenance / Modification
Repair and correction Repairs may only be carried out with original parts of SAMCON Prozessleittechnik GmbH. Damaged pressure-resistant housings have to be replaced completely. In case of doubt, send the part in question back to SAMCON Prozessleittechnik GmbH. -
Page 27: Drawings, 3D Models, Certificates And Further Documentation
Drawings, 3D models, certificates and further documentation All drawings, 3D models, certificates and other information are available in the download area of the product page on our website: https://www.samcon.eu/en/products/network/excam-ipm1137/ If you wish additional technical information, please contact us at: support@samcon.eu... - Page 28 Schillerstrasse 17, 35102 Lohra-Altenvers, Germany www.samcon.eu, info@samcon.eu Phone: +49 6426 9231-0, fax: - 31...
